Aluminium Sliding Door With Double Glazing

US$ 50 - 200 MOQ: 100 Square Meters

Key Specifications

Place of Origin:

Jiangsu, China

Brand Name:

GRI

Model Number:

GRI 80D-03

Wuxi GRI Construction Engineering Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai China

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Jiangsu, China

Brand Name GRI

Model Number GRI 80D-03

Open Style Sliding

Position Exterior

Surface Finishing Finished

Type Sliding Doors

Sliding Door Type Partition Doors

Door Material Aluminum Alloy

Specifications

Aluminum Glass Sliding Door
1. Surface: powder-coated, PVDF
2. Glass: single or double.
3. Size: customsized

Aluminum sliding window Technical Data
Items	Description	Notes
1. Material	Aluminum 6063 T5 / 6063 T6	Customized
2. Profile thickness	1.2mm-2.0mm or thermal break aluminum	Customized
3. Surface treatment	Powder coating, Electrophoresis painting, Fluoro carbon painting
4. Glass specification	Low-E glass, Tempered glass, OBS glass, etc.	Customized
	Thickness: 4mm, 5mm, 6mm, 8mm, etc.
	Space: 6mm, 9mm, 12mm, 16mm, etc.
5. Hardware	Schuco, Kinlong or local brand	Customized
6. Color	Refer to the color card	Customized
7. Perforamcne parameters	Sounds insulation: GB/T 8485-2008	RW ≤ 28 dB
	Wind pressure resistance: GB/T7106-2008	2.5~3.0Kpa
	Air permeation resistance: GB/T7106-2008	0.5~1.0m³/(mh)
	Water resistance: GB/T7106-2008	250~350Pa
	Thermal insulating properties: GB/T8484-2008	K=2.5~3.0W/ (m ² K)
	The horizontal tension: GB/T8478-2008	< 100N
8. Applicable place	House, apartment, hotel, office, etc.
Trade term & load quantity:
Payment	TT, L/C
Lead Time	30-35 days vary by order quantity
20ft	200pcs for window with normal size(1.2mx1.2m)
20ft	90pcs for Doors with normal size(1.8mx2.2m)
40ft	420pcs for window with normal size(1.2mx1.2m)
40ft	200pcs for Doors with normal size(1.8mx2.2m)
40HQ	530pcs for window with normal size(1.2mx1.2m)
40HQ	250pcs for Doors with normal size(1.8mx2.2m)
