Help Center5kva Diesel Generator
Negotiable
MOQ: 2 Cartons (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Usage:
Automobile
Fuel:
Diesel
Stroke:
4 Stroke
Payment & Shipping
Payment Methods:
Port of Shipment:
SHANGHAI
Delivery Detail:
Delivery time depends on order quantity.
Related Products
Usage
Automobile
Fuel
Diesel
Stroke
4 Stroke
Cylinder
Single Cylinder
Cold Style
Other, Air-cooled
Start
Electric Start
Place of Origin
Jiangsu, China
Brand Name
KOOP
Model Number
KDF6700Q
Certification
CE
| Model | KDF6700Q | |
|
| Rated frequency (Hz) | 50 | 60 | |
| Rated voltage (V) | 220, 230, 240, 220/110, 230/115, 240/120 | ||
| Rated output power (KVA) | 4.2 | 4.5 | |
| Rated rotation speed (rpm) | 3000 | 3600 | |
| DC output | 12V, 7A | |
|
| Power factor cosφ | 1 | |
|
| Phase number | Single phase | |
|
| Excitation mode | Self-excitation Brushless | ||
| Noise level dB(A)@ 7m (zero load - full load) | 70-74 | ||
| Overall dimension [mm(in)](L×W×H) | 920×520×700 | |
|
| 36.22×20.47×27.56 | |
||
| Net weight [kg(lbs)] | 140 (308) | |
|
| Structure model | Low noise type with enclosure | |
|
| Connection mode | Single bearing, rotor drive shaft, rigid coupling | |
|
| Engine model | KD186FE | |
|
| Engine type | 1-cylinder, 4-stroke, air-cooled, direct injection, diesel engine | |
|
| Displacement [cm³(Cu-in)] | 406 (24.78) | |
|
| Compression ratio | 19:01 | |
|
| Rated power [KW(Hp)/rpm] | 6.3 (8.6)/3600 | |
|
| Starting system | Electric starting | |
|
| Rotation direction (view from flywheel) | Clockwise | |
|
| Fuel type | 0 (sumber), 10 (winter) diesel oil | |
|
| Lube | SAE10W30 (above CC grade) | |
|
| Low oil pressure alarm system | With | |
|
