304 Stainless Steel Biometric Full Height Turnstile

 Specification

Material:

304 stainless steel or Cold-rolled steel plate.

Drive mode:

Inner core use 16 Bit Microprocessor,can processed by customer's requirement

Signal interface:

1.Passive node

2.TTL Rssia

3.RS485 interface

4.TCP/IP interface (optional)

Width of passage:

600mm

Following Speed:

≥25 people/minute

Noise:

≤65dB

Working state:

single or bi-direction

Status Indication:

Allow passing through / Forbidden

Close and Open time:

1 Second

Power supply:

Input AC220V (adjustable)

Optional:DC24V±10% 3A ;DC12V±10% 3A

Communication Interface:

two Card reader signals

Working environment:

Indoor, outdoor

Working temperature

-20°to +65°

Humidity:

5%-90%

Maintenance port:

 1unit

Service Life:

Three million contiguous opening and closing of barrier panel.

Dimension:

120degree, 2324*1408*2301mm

Net Weight:

Approx 150KG

Feature & Advantages

1.Cold-rolled steel plate or 304 stainless steel casing optional.

2.Directional LED Optical Signals:Green Arrow or RED Cross signage.

3.Mechanism is specially processed ,more durable

4.Ensures rapid, efficient & safe access control.

5.Individual installation interface,easy to integrated with Magnetic card,Barcode card,ID card,IC card etc.

6.PhotoElectric Beams installed standard for all models.
