5 Axis CNC Breakout Board

5 Axis CNC Breakout Board thumbnail-1
5 Axis CNC Breakout Board photo-1
US$ 15 - 28 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
DEWO
Motor Type:
Other, Stepper motor driver
Contact Supplier Request Quote Chat Now
Changzhou Dewo International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Jiangsu, China
Brand Name DEWO
Motor Type Other, Stepper motor driver

1.Features:
1.full support for MACH3, KCAM4, EMC2, and support parallel
port to control the host computer software;
2.5 output signal ,can connect with 5 stepper motor driver ;
3.4 input port, Can connect to the limit switch, emergency stop,
or other Input devices ;
4.One relay, it can be used to control spindle start and stop;
5.Interface board built-in 5V power converter chip, can be
connected with DC 12V-60V power supply.



2.Electrical drawing

5 Axis CNC Breakout Board

3.limit switches and emergency stop
switch connection methods:
Input interface, you can access limit, emergency stop switch can also
be connected to the reset, the knife and other input devices, when used
according to the actual situation of your set of reference the following
figure:

4.Definition on pins of parallel port: 5 Axis CNC Breakout Board
