Help CenterWorm Gearbox Motor Nema 15 ,39mm pm Motor Stepper, 4 Phase Hybrid Step Motor ,motor for Overlock
Related Products
-
Geared Nema 14 Electric Stepper Motor Factory, High TorqueUS$ 5.99 - 8.99MOQ: 1 Piece -
Worm Gearbox Motor Nema 15 Stepper Motor Mini ,3kg Torque Servo MotorUS$ 5.99 - 8.99MOQ: 1 Piece
-
High Torque Nema 17 42mm 2 Phase Micro Engine Motor Step for Cnc Machine Quality ChoiceUS$ 7.5 - 9MOQ: 1 Piece
-
Low Price Motor Stepper Nema 15 39mm pm Stepper Motor in RoboticsUS$ 5.99 - 8.99MOQ: 1 Piece
-
High Torque Nema 17 42mm 2 Phase Stpe Motor for Cnc MachineUS$ 7.5 - 9MOQ: 1 Piece
Step Angle |
1.8° |
Step Angle Accuracy |
±5% (full step,no load) |
Resistance Accuracy |
±10% |
Inductance Accuracy |
±20% |
Temperature Rise |
80°CMax.(rated current,2 phase on) |
Ambient Temperature |
-10°C to +50°C |
Insulation Resistance |
100MΩMin. 500VDC |
Dielectric Strength |
500VAC for one minute |
Shaft Radial Play |
0.06Max.(450 g-load) |
Shaft Axial Play |
0.08Max.(450 g-load) |
Model No |
Current/Phase |
Resistance/Phase |
Inductance/Phase |
Holding Torque |
#Of Leads |
Rotor Inertia |
Weight |
Length |
|
A |
Ω |
mH |
Oz-in |
g-cm |
g-cm2 |
Kg |
mm |
||
DW39HS20-0404 |
0.40 |
6.6 |
7.5 |
9 |
650 |
4 |
11 |
0.12 |
20 |
DW39HS20-0506 |
0.50 |
13 |
7.5 |
11 |
800 |
6 |
11 |
0.12 |
20 |
DW39HS34-0654 |
0.65 |
7 |
9.3 |
25 |
1800 |
4 |
20 |
0.18 |
34 |
DW39HS34H-0404 |
0.40 |
30 |
32 |
29 |
2100 |
4 |
20 |
0.18 |
34 |
DW39HS34H-0604 |
0.60 |
15 |
16 |
31 |
2200 |
4 |
20 |
0.18 |
34 |
DW39HS34H-0606 |
0.60 |
40 |
21 |
18 |
1300 |
6 |
20 |
0.18 |
34 |
DW39HS34H-0166 |
0.16 |
75 |
50 |
15 |
1100 |
6 |
20 |
0.18 |
34 |
DW39HS38H-0504 |
0.50 |
24 |
45 |
40 |
2900 |
4 |
28 |
0.2 |
38 |
DW39HS38H-0806 |
0.80 |
7.5 |
6 |
28 |
2000 |
6 |
28 |
0.2 |
38 |
DW39HS44H-0304 |
0.30 |
40 |
100 |
39 |
2800 |
4 |
36 |
0.25 |
44 |
