Technique parameter
Item |
Specification |
Step Angle |
1.8° |
Step Angle Accuracy |
±5% (full step,no load) |
Resistance Accuracy |
±10% |
Inductance Accuracy |
±20% |
Temperature Rise |
80°CMax.(rated current,2 phase on) |
Ambient Temperature |
-10°C~+50°C |
Insulation Resistance |
100MΩMin. 500VDC |
Dielectric Strength |
500VAC for one minute |
Shaft Radial Play |
0.06Max.(450 g-load) |
Shaft Axial Play |
0.08Max.(450 g-load) |
DW86HS Motor Name List(Square)
Model No |
Current |
Resistance |
Inductance |
Holding Torque |
#Of Leads |
Rotor Inertia |
Detent Torque |
Weight |
Length |
||
A |
Ω |
mH |
Oz-in |
Kg-cm |
g-cm2 |
(kg.cm) |
Kg |
mm |
|||
DW86HS65-2808 |
2.80 |
1.4 |
3.9 |
250 |
18 |
8 |
1000 |
0.8 |
1.7 |
65 |
Φ14*37 |
DW86HS65-5904 |
5.90 |
0.28 |
1.7 |
250 |
18 |
4 |
1000 |
0.8 |
1.7 |
65 |
Φ14*37 |
DW86HS75-2008 |
2.00 |
2.2 |
10 |
291 |
21 |
8 |
1400 |
1.7 |
75 |
Φ14*37 |
|
DW86HS75-4004 |
4.00 |
0.5 |
2.5 |
347 |
25 |
4 |
1400 |
1.7 |
75 |
Φ14*37 |
|
DW86HS80-4208 |
4.20 |
0.75 |
3.4 |
486 |
35 |
8 |
1400 |
1.2 |
2.3 |
80 |
Φ14*37 |
DW86HS80-5504 |
5.50 |
0.46 |
4 |
486 |
35 |
4 |
1400 |
1.2 |
2.3 |
80 |
Φ14*37 |
DW86HS94-2008 |
2.00 |
3.2 |
15 |
611 |
44 |
8 |
1700 |
2.1 |
94 |
Φ14*37 |
|
DW86HS94-4008 |
4.00 |
0.8 |
3.5 |
597 |
43 |
8 |
1700 |
2.1 |
94 |
Φ14*37 |
|
DW86HS113-3504 |
3.50 |
0.53 |
6.5 |
763 |
55 |
4 |
2700 |
2.8 |
113 |
Φ14*37 |
|
DW86HS113-6008 |
6.00 |
0.43 |
2.5 |
763 |
55 |
8 |
2700 |
2.8 |
113 |
Φ14*37 |
|
DW86HS118-4208 |
4.20 |
0.9 |
6 |
833 |
60 |
8 |
2700 |
2.4 |
3.8 |
118 |
Φ14*37 |
DW86HS118-6004 |
6.00 |
0.6 |
6.5 |
902 |
65 |
4 |
2700 |
2.4 |
3.8 |
118 |
Φ14*37 |
DW86HS151-2008 |
2.00 |
3.9 |
20 |
1110 |
80 |
8 |
3600 |
3.7 |
151 |
Φ14*37 |
|
DW86HS151-3004 |
3.00 |
1.9 |
22 |
1110 |
80 |
4 |
3600 |
3.7 |
151 |
Φ14*37 |
|
DW86HS156-4208 |
4.20 |
1.25 |
8 |
1180 |
85 |
8 |
4000 |
3.6 |
5.4 |
156 |
Φ14*37 |
DW86HS156-6204 |
6.20 |
0.75 |
9 |
1249 |
90 |
4 |
4000 |
3.6 |
5.4 |
156 |
Φ14*37 |
