Help CenterLT 13-560 High Carbon Wet Wire Drawing Machine Manufacturer for Mattress Spring Quality Choice
Related Products
-
Heavy Water Tank Metal Wire Drawing Machine For Cable Making Quality ChoiceUS$ 1,000 - 20,000MOQ: 1 Set -
LT11/560 Water Tank/Wet Type Drawing MachineUS$ 1,000 - 20,000MOQ: 1 Set
-
Some Copper Wire Wet /Water Tank Type Drawing MachineUS$ 1,000 - 20,000MOQ: 1 Set
-
Water Tank Copper Wire Drawing Machine/Wet Type Wire Drawing Machine MachineryUS$ 1,000 - 20,000MOQ: 1 Set
-
Model LT1-17/350 Fine Wire Wet Drawing MachineUS$ 1,000 - 20,000MOQ: 1 Set
Low space Turnover Wet wire drawing machine (Manufacturer)/wire coil machine/descaling machine
Specifications
1) Min. order: 1 set
2) Package details: as the normal export
3) Delivery time : 2 months
4) Payment terms: L/C T/T
Wire Drawing Machine/water tank Drawing machine/ Drawing Machine Factory
Drawing Machine Factory
----------------------------------------------
1. Feature of the drawing machine
The drawing machine applies advanced international technology,with digestion and absorption, the drawing machine id applicable for high intesity and performance demand. It mainly applied for the production of steel curtain wire,tyre steel wire ,steel wire for rope,spring steel wire ,stainless steel wire etc. The capston diameter of the straight line drawing machine series products is Φ350- Φ1200mm with maxium inlet diameter of Φ14mm and minimum outlet diameter of 0.7mm.
The equipment of the straight line drawing machine contains the function of human-machine dialogue,over tempertureprotaction for the moter,alarm for abnormal water pressure,fault display,ect. the capston appled the combination of the narrow water cooling and air cooling with good cooling effect. Generally it is an kind of efficient and advanced drawing wquipment with easy operation,high degree of automation and aboard process scope.
Main Technical Parameters
Product Specification
- Capstan: special treatment, longer using life.
- Coiling drum: double layer, high precision. Keep coil’s quality.
- Gear transmission, first class gearbox.
- Electric parts: Famous brand from domestic and abroad.
Main Technical Parameters
Model |
LTA11/450 |
LTA13/450 |
LTA15/450 |
LTA17/450 |
LTB15/450 |
LTB17/450 |
LTA15/350 |
LTA17/350 |
Capstan dia |
Φ450mm |
Φ450mm |
Φ450mm |
Φ450mm |
Φ450mm |
Φ450mm |
Φ350/450mm |
Φ350/450mm |
Drawing dies |
11 |
13 |
15 |
17 |
15 |
17 |
15 |
17 |
Max.inlet dia |
Φ4.8mm |
Φ4.8mm |
Φ5.5mm |
Φ5.5mm |
Φ4.0mm |
Φ4.0mm |
Φ3.5-1.1mm |
Φ3.5mm |
Min.outlet dia |
Φ1.8mm |
Φ1.4mm |
Φ1.4mm |
Φ1.2mm |
Φ1.2mm |
Φ1.0mm |
Φ1.1mm |
Φ1.0mm |
Drawing speed |
300m/min |
300m/min |
300m/min |
300m/min |
320m/min |
320m/min |
320m/min |
320m/min |
Inlet wire intensity |
≤1150Mpa |
≤1150Mpa |
≤1150Mpa |
≤1150Mpa |
≤1150Mpa |
≤1150Mpa |
≤1250Mpa |
≤1250Mpa |
Total compression rate |
84% |
90.32% |
93.24% |
95.24% |
91% |
93.75% |
90.1% |
91.57% |
Average compression rate |
15.35% |
16.44% |
16.44% |
16.40% |
14.80% |
15.05% |
14.3% |
13.54% |
Motor power |
90-75KW |
90-75KW |
110-90KW |
110-90KW |
75KW |
75KW |
45-75KW |
45-75KW |
External dimensions |
5780×3300×1640 |
4500×3200×1500 |
3300×1640×1500 |
|||||
LT13/560 High carbon wire wet drawing machine
Max Inlet size |
Φ6.5mm |
Min Outlet size |
Φ1.4mm |
Inlet tensile strength |
≤1150MPa |
Capstan diameter |
Φ560mm |
Line speed |
300m/min |
About us
Wuxi Wandeshun Machine Co., Ltd. one of the leading wire drawing machine manufacturers in China , is specialized in manufacturing wire drawing machines , which was established in 2000.
Our products are popular in many provinces of china and have already been exported to Vietnam , Indonesia, Uzbekistan Kenya, South Africa,Algeria,Egypt, Iran,Turkey and so on.
Excellent geographic location and easy transportation access, only 2k meter from Wuxi airport and adjacent to national highway 312.Welcome friends of all industries to visit and instruct our factory.
Main products: Straight line drawing machine
Water tank wire drawing machine
Aluminium wire drawing machines
Vertical wire drawing machine
Pulley wire drawing machine
We have a professional technical team, a good after-sale service team, an excellent production management team. We can design and produce various wire drawing machines, auxiliary equipment according to customers’ special requirements
