Automatic Coil Nail Machine

Automatic Coil Nail Machine photo-1
US$ 1,000 - 8,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Jiangsu, China
Brand Name:
wxwds
Model Number:
Z94 Series
Payment & Shipping
Payment Methods:
Port of Shipment:
shanghai
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Jiangsu, China
Brand Name wxwds
Model Number Z94 Series
After-sales Service Provided Engineers available to service machinery overseas

Specifications

Coiled nails machine :
1.Length of nail:75-100mm
2.Diameter of nail:2.7-3.3mm
3.Capacity (pieces/m):800-1800

                                       Coil Nail Making Machine



Features:

This machine adopts plunger type structure to ensure high working speed, low noise and low impact characteristics. and this machine can also make many types of nails that you may wantto produce.



Technical parameter:

Model

Z94-1C

Automatic nail making machine

Z94-2C

Automatic nail making machine

Z94-3C

Automatic nail making machine

Z94-4C

Automatic nail making machine

Z94-5.5C

Automatic nail making machine

Max. dia. of nail

1.6mm

2.8mm

3.5mm

4.5mm

5.5mm

Min. dia. of nail

0.9mm

1.2mm

1.8mm

2.8mm

3.8mm

Max. Length of nail

25mm

50mm

75mm

100mm

150mm

Min. length of nail

9mm

16mm

30mm

50mm

80mm

Motor power

1.5kw

2.2kw

3kw

4kw

5.5kw

Nail making speed

450pcs/min

350pcs/min

320pcs/min

260pcs/min

200pcs/min

L*W*H

1.5*1.3*1.2m

1.7*1.3*1.4m

2.0*1.4*1.4m

2.2*1.6*1.65m

2.5*1.6*1.5m

W eight

1.2tons

1.45tons

1.8tons

2tons

2.3tons




Data of coil nail making machine:

Electric parts

Title

Parameter

Working power

Three phare AC 380V 50-60HZ

Welding mains

DC 290-330V

Rated power

8KVA

Max power

12KVA

Welding electricity

1000-2000A(secondary side)



Specification

Title

Diameter(mm)

Length(mm)

Speed(piece/minute)

Hat-peg

2.7-3.3

75-100

800-1800



Machinery part

Title

Paremeter

Coil

Length×wideth×high=3000×900×1100mm

Vibration plate

1500-1850pices/min

Air pressure

≥0.4~0.8Mpa

Colling water

Plus a small pump circulating

,pressure 0.1~0.2Mpa

weight

About 1600KG
