Product Details
Inverted Vertical Steel Wire Drawing Machine/Bolts making machine for fastener industry
Single die wire drawing machine
It is applicable for continuous production process of coil with heavy charging box.
The product is developed for the non-slip drawing of medium & low carbon steel wire, special shaped steel wire and nonferrous metals with thick & medium diameters. It is specially suitale for the drawing of medium & low carbon steel wire in standard parts and supermarket shelf industry. The maximum inlet diameter can reach 30mm and diameter of capstan is 550-1300mm.
Transmission part of the system can apply cycloidal speed reducer, harden gear surface reducer orrockerreducer. Its electric system applies international famous brand frequency converter with stable performance.
Specification
| Items | Unit | Model |
| Capstan diameter | mm | 800 |
| Maximum diameter of inlet wire | mm | 40 |
| Intensity of material | Mpa | ≤1200 |
| Compression rate | % | 20 |
| Maximum drawing speed | m/s | 2.5 |
| Motor power | kw | 11-110 |
Features
1.It is applicable for continuous production process of coil with heavy charging box.
2.Easy operation and reliable control enables safe production and convenient maintenance.
3.Application of 3- phase AC variable- frequency speed adjustment realizes smooth step less speed regulation and saves more than 30% electric power.
AUTO -pay off machine for big size match with the vertical wire drawing machine
-----------------------------------------------------------
Be up to the international level. Our lines and related complete equipment have been exported to Southeast Asia, West Asia, Eastern Europe, South America, the Middle East, Russia, India, Indonesia, Morocco, South Africa, Algeria, etc.
our loading and shipment and with our clients photos
