Specifications
copper rod input diameter:8mm,output diameter: 1.78mm-3.30mm
annealing: continuous annealing
Brand Name: WDS
Specifications
LT9-450Copper Large Pull with continuous annealing production line
copper rod breakdown machine;rod breakdown machine;8mm copper rod dawing machine
From 8mm to 1.78mm—3.30mm
copper rod input diameter:8mm,
output diameter: 1.78mm—3.30mm
production speed:480meters/s
production capacity: 1200KG/hour
copper rod breakdown wire drawing machine (450/LT9)
number of dies:9
installed capacity:125KVA (Main motor:AC.110KW,spooler motor:15KW)
drive: frequency inverters
Dimension length 3000 * 1800mm Weight 6.5T width
opper rod breakdown machine;rod breakdown machine;8mm copper rod dawing machine
this Copper rod breakdown machine is used to draw single bare copper wire from 8mm to 1.78mm—3.30mm
.The drawing capstans are arranged in a line that are able to work continuously with drawing speed and speed of mechanical parts and electrical control can be matched with each other. It is easy to operate, easy to change dies quickly. This machine has features of easy and convenient operation, high efficiency and good quality of product.
LT-1200 large Pull continuous annealing line supporting equipment as follows:
Actinomyces gantry frame wear die rolling machine 110KW motor control cabinet tip LT-9 mold copper big pull
LT-1200 annealing machine LT-1200 cabinet annealing operation of the main electrical cabinet automatic double-disc MD-up Machine XB-600 like the nose and unloading-ray machine (also purchased) can store 1 tonne of copper wire used in the production line when a large single-core BV capacity pay-off.
