1. About us-we are professional factory for wire drawing
Wuxi Wandeshun Machine Co., Ltd. one of the leading wire drawing machine manufacturers in China , is specialized in manufacturing wire drawing machines , which was established in 2000.
Our products are popular in many provinces of china and have already been exported to Vietnam , Indonesia, Uzbekistan Kenya, South Africa,Algeria,Egypt, Iran, Turkey and so on.
Excellent geographic location and easy transportation access, only 2k meter from Wuxi airport and adjacent to national highway 312.Welcome friends of all industries to visit and instruct our factory.
My contact way
My mobile: 86-13921534531
Whatsapp: 86-13921534531
Skype: jeaqueline998
trademanager: wxwds
Email:sales(at)
QQ:349791577
Product Details
Cold rolling ribbed bars machine
Type |
WDS-550-650 |
Max .inlet Diameter |
14mm |
Rolling Specifications |
4-12mm |
Rolling linear speed |
120m/min. |
Motor Capacity |
37kw |
Motor Frequency Inverter |
37kw |
Mode of adjustment speed |
Inverter |
Weight |
8T |
Wire spool |
1000kg/bundle |
Installed length |
16 meters |
Cold rolling ribbed bars machine
This Cold-rolled ribbed steel bar production line equipment is rolled coiled steel by cold rolling,
cold rolling and then its surface to form three sides of a crescent reinforced by transverse ribs
straightening, processed into a cast or prefabricated construction directly cold-rolled ribbed
steel bars. This production line mainly rolls diameter of 4—12mm and ordinary low carbon
tray bar or low alloy tray bar with multiple cold rolling and a ribbing rolling, which finally forms
reinforcing steel with three-side crescent shape ribs. The raw material is hot-rolled low carbon
wire rod tray bar. It's widely applicable to highway, airport, irrigation works, city planning and
construction engineering.
General description:
The rolling cassette plant equipped with carbide die (cassette) instead of fixed wire drawing die, it is installed upon the straight line wire drawing machine, the cassette matched with angular cutter gear and mump lubricate system, to produce the low carbon, middle carbon and high carbon steel wire, also can produce the copper, aluminum and titanium, it increased the drawing and rolling speed.
Technical parameter:
Capstan dia. : 600mm
Incoming wire dia.: 6.5mm, 6.0mm and 5.5mm
Outgoing wire dia.: 3.5-5mm
Total compressibility: 85%
Wire roller speed: 10m/s
Single motor power: 35 KW
Capstan number: according to the inlet wire diameter and outlet wire diameter
Gear description: Angular milling gear
Lubrication of gears and bearings: Oil pump compulsion lubrication
The whole production line which we ship to Turky last year for ribbed wire making
In order to guarantee the customers are able fully to operate the machine, if the customer need, we can help customer training, includes:
(1) Correct operating mode
(2) Correct maintenance way
(3) Remove simple problem
All the products of our company have already been widely used in metal products area.
our clients and our machine
