iron sheet bending machine
1.The application of iron sheet bending machine |
The folded sheet metal bending machine has high productivity and high working accuracy, using different shapes of up and down mould, can be bent into various shapes artifacts, slider stroke at a time can be to a bending forming of sheet metal, after a lot of bending can be achieved relatively complex shape workpiece, when equipped with the corresponding equipment, can also make a punch
2.Main technical parameter |
Hydraulic press brake wc67 series | ||||||||
Specification |
Pressure KN |
Worktable length mm |
Distance between uprights mm |
Throat Depth mm |
Stroke mm |
Opening height mm |
Main motor KW |
Weight |
WC67K-40/2000 |
400 |
2500 |
1550 |
250 |
120 |
325 |
4 |
2600 |
WC67K-40/2500 |
400 |
2500 |
2050 |
250 |
120 |
325 |
4 |
3000 |
WC67K-63/2500 |
630 |
2500 |
2050 |
250 |
120 |
330 |
5.5 |
4200 |
WC67K-63/3200 |
630 |
3200 |
2600 |
250 |
120 |
330 |
5.5 |
5100 |
WC67K-80/2500 |
800 |
2500 |
2050 |
320 |
120 |
370 |
7.5 |
5800 |
WC67K-80/3200 |
800 |
3200 |
2600 |
320 |
120 |
370 |
7.5 |
6100 |
WC67K-100/2500 |
1000 |
2500 |
2050 |
320 |
120 |
380 |
7.5 |
6000 |
WC67K-100/3200 |
1000 |
3200 |
2600 |
320 |
120 |
380 |
7.5 |
6600 |
WC67K-100/4000 |
1000 |
4000 |
3200 |
320 |
120 |
380 |
7.5 |
8100 |
WC67K-125/3200 |
1250 |
3200 |
2600 |
320 |
120 |
380 |
7.5 |
7000 |
WC67K-125/4000 |
1250 |
4000 |
3200 |
320 |
120 |
380 |
7.5 |
8500 |
WC67K-160/3200 |
1600 |
3200 |
2600 |
320 |
180 |
450 |
11 |
9500 |
WC67K-160/4000 |
1600 |
4000 |
3200 |
320 |
180 |
450 |
11 |
11200 |
WC67K-200/3200 |
2000 |
3200 |
2600 |
320 |
200 |
470 |
15 |
12700 |
WC67K-200/4000 |
2000 |
4000 |
3200 |
320 |
200 |
470 |
15 |
15300 |
WC67K-250/3200 |
2500 |
3200 |
2600 |
400 |
250 |
530 |
18.5 |
15700 |
WC67K-250/4000 |
2500 |
4000 |
3200 |
400 |
250 |
530 |
18.5 |
18500 |
WC67K-300/3200 |
3000 |
3200 |
2600 |
400 |
250 |
560 |
22 |
19400 |
WC67K-300/4000 |
3000 |
4000 |
3200 |
400 |
250 |
560 |
22 |
21700 |
WC67K-300/6000 |
3000 |
6000 |
4700 |
400 |
250 |
560 |
22 |
29600 |
WC67K-400/4000 |
4000 |
4000 |
3200 |
400 |
300 |
640 |
30 |
30000 |
WC67K-400/6000 |
4000 |
6000 |
4700 |
400 |
300 |
640 |
30 |
34500 |
WC67K-500/4000 |
5000 |
4000 |
3200 |
500 |
300 |
640 |
37 |
31800 |
WC67K-500/6000 |
5000 |
6000 |
4700 |
500 |
300 |
640 |
37 |
43200 |
WC67K-600/6000 |
6000 |
6000 |
4700 |
500 |
300 |
650 |
45 |
53500 |
3.Features |
1).Holistic welding structure
2).ESTUN E200 special CNC system for press brake(double axes) is optional
3).the drive element of backgauge adopts importing ball screw and linear guideway
4)CNC system DA52,DA56,DA66WE,DA41,E210 is optional
...
