Home > Manufacturing & Processing Machinery > Machine Tools > Punching Machine > Pneumatic Power Press CNC MECHANICAL POWER PRESS MACHINE
Pneumatic Power Press CNC MECHANICAL POWER PRESS MACHINE
Negotiable
MOQ: 1 Set (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Condition:
New
CNC or Not:
Normal
Power Source:
Mechanical
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.
Related Products
-
Pneumatic Crank Power Press, Stroke Adjustable PressNegotiableMOQ: 1 Set -
Sheet Metal Punch Presses CNC MECHANICAL POWER PRESS MACHINENegotiableMOQ: 1 Set
-
Sheet Metal Press Die Metal Stamping PressNegotiableMOQ: 1 Set
-
Power Press Punch Press CNC MECHANICAL POWER PRESS MACHINENegotiableMOQ: 1 Set
-
Mechanical Hardware Fitting Power PressNegotiableMOQ: 1 Set
Condition
New
CNC or Not
Normal
Power Source
Mechanical
Place of Origin
Anhui, China
Brand Name
Baide
Model Number
J23
Voltage
380V
Power(W)
1500
Weight
1400 kg
Dimension(L*W*H)
1100*780*1800
Certification
CE
Warranty
1 year
After-sales Service Provided
Overseas third-party support available
pneumatic power press
Main parameters (Optional)
| No. | Specification | J23-16T | ||
| 1 | Nominal force(kn) | 160 | ||
| 2 | Nominal force stroke(mm) | 5 | ||
| 3 | Slider stroke(mm) | 60 | ||
| 4 | Stroke frequency(times/min) | 110 | ||
| 5 | The largest closed height(mm) | 220 | ||
| 6 | Closed height adjustment(mm) | 50 | ||
| 7 | Distance between slider center and the fuselage | 180 | ||
| 8 | Work table size | F-B(mm) | 300 | |
| L-R(mm) | 450 | |||
| 9 | Diameter of blank-holding hole | F-B(mm) | 130 | |
| L-R(mm) | 200 | |||
| Diameter(mm) | 120 | |||
| 10 | Slider bottom size | F-B(mm) | 130 | |
| L-R(mm) | 220 | |||
| 11 | Hole size for die handle | Diameter(mm) | 40 | |
| Depth (mm) | 60 | |||
| 12 | The distance between columns (mm) | 170 | ||
| 13 | Nat distance between work table to guide rail (mm) | 250 | ||
| 14 | Backing board thickness(mm) | 45 | ||
| 15 | Body tilting angle( °) | 30 | ||
| 16 | Motor | rate(kw) | 1.5 | |
| speed(r/s) | 1410 | |||
| 17 | Frame dimension | L-R(mm) | 1100 | |
| F-B(mm) | 780 | |||
| height (mm) | 1800 | |||
