Steel Sheet Metal Press High Precision Wide Application Pneumatic Press

Name: Steel Sheet Metal Press High Precision Wide Application Pneumatic Press
Brand: Baide
SKU: 106246499
Availability: InStock

Negotiable MOQ: 1 Set (Price negotiable depending on order volume and customization)

Key Specifications

Condition:

New

CNC or Not:

Normal

Power Source:

Mechanical

Maanshan Baide CNC Machinery Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai

Delivery Detail:

Delivery time depends on order quantity.

Condition New

CNC or Not Normal

Power Source Mechanical

Place of Origin Anhui, China

Brand Name Baide

Model Number JH21

Voltage 380V

Power(W) 2200

Weight 1600 kg

Dimension(L*W*H) 1175 x 1050 x 1830MM

Certification CE

Warranty 1 year

After-sales Service Provided Overseas third-party support available

Main parameters (Optional)

Items		JH21-63T	JH21-80T
Nominal force(KN)		630	800
Stroke of nominal force (mm)		4	5
Slide stroke(mm)		120	140
Times of slide stroke(times/min)	Fixed	70	60
Times of slide stroke(times/min)	Variable	60-80	50-70
Maximum height for die loading(mm)		300	320
Adjustment for die height(mm)		80	80
Distance of Slider center to frame(mm)		300	300
Distance between columns(mm)		560	640
	Left and right(mm)	480	560
Bottom size of slide	Front and back(mm)	400	420
	Diameter(mm)	50	50
Hole size for die handle	Depth(mm)	80	80
	Left and right(mm)	900	1000
Size of worktable	Front and back(mm)	580	580
	Thickness	110	120
Size of worktable’s Blanking hole(mm)	Diameter of Upper hole	Φ200	Φ200
	Depth	Φ40	Φ40
	Diameter of Lower hole	Φ180	Φ180
Main motor (Kw)		5.5	7.5
	Front and back	1580	1640
Dimensions	Left and right	1210	1280
	Height	2520	2700
Weight		5400	7000
