Solar Panel Glass Tempering Furnace

Name: Solar Panel Glass Tempering Furnace
Brand: LIDU
SKU: 106245945
Availability: InStock

Solar Panel Glass Tempering Furnace thumbnail-1

Solar Panel Glass Tempering Furnace photo-1

US$ 50,000 - 70,000 MOQ: 1 Set

Key Specifications

Get Latest Price

Condition:

New

Machine Type:

Glass Tempering Furnace

Production Capacity:

820 S meter/hour

Contact Supplier Request Quote Chat Now

Haining Lidu Glass Machine Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shanghai/Ningbo

Delivery Detail:

Delivery time depends on order quantity.

Product Details
Company Profile
Contact Us

Condition New

Machine Type Glass Tempering Furnace

Production Capacity 820 S meter/hour

Place of Origin Zhejiang, China

Brand Name LIDU

Model Number LDGL1630

Voltage 380v

Power(W) 2800KW

Certification Other, CE, ISO9001:2000

Warranty 1 year

After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Glass tempering furnace
2.Outstanding energy-saving
3.High production efficiency
4.Strong stability
5.CE certificate

Continuous glass tempering furnaces/ LDGL1630

It can process glass of diameter 40 mm and thickness 2.5mm with good flatness after tempering .It also can process intensified glass with thickness 1.8mm.

Characteristics

1.Through adopting the continuous transmission and heating techniques, LPG is able to reduce the friction between the surface of the glass and the surface of the ceramic rollers so that it can improve the glass quality.

2.The use of lower temperature entry of the furnace and improve the controlling techniques avoid the breakage of the surface of the glass after the entry.

3.The capacity is several times to the traditional ones.

4. It will save energy with continuous entry and tempering.

Mainly in

Volume-produce on solar energy high-end home appliance ,interior decoration, architectural glass with high quality.

Parameters

Type	Max.Glass Size(mm)		Min.Glass Size(mm)		Glass Thickness(mm)		Capacity (m /h)		Installation Power(kw)
LDGL0720	750×2000		200×300		3-6		135		800
LDGL0920	900×2000		200×300		3-6		165		900
LDGL1220	1250×2000		200×300		3-6		230		1300
LDGL1620-A	1600×2000		200×350		3-6		270		1500
LDGL1620-B	1600×2000		200×350		3-10		375		1800
LDGL1620-C	1600×2000		200×350		3-10		740		2300
LDGL1630	1600×3000		200×350		4-12		820		2800
LDGL2040-A	2000×4000		200×350		4-12		550		2500
Type		Max.Glass Size(mm)		Min.Glass Size(mm)		Glass Thickness(mm)		Capacity (m2 /h)		Installation Power(kw)
LDGL0720		750×2000		200×300		3-6		135		800
LDGL0920		900×2000		200×300		3-6		165		900
LDGL1220		1250×2000		200×300		3-6		230		1300
LDGL1620-A		1600×2000		200×350		3-6		270		1500
LDGL1620-B		1600×2000		200×350		3-10		375		1800
LDGL1620-C		1600×2000		200×350		3-10		740		2300
LDGL1630		1600×3000		200×350		4-12		820		2800
LDGL2040-A		2000×4000		200×350		4-12		550		2500

Remark

All sizes are based on millimeter and the capacity subjected to 5mm glass at 80% utilization and 100% end-product rate. The change of equipment configuration will be in accordance with the different of glass thickness range,it is depended on actual design.
