Specifications
1.Glass tempering furnace2.Outstanding energy-saving
3.High production efficiency
4.Strong stability
5.CE certificate
Double chambers flat glass Tempering furnaces/ /LDGS2003
Mainly in
Solar energy high grade domestic appliances, interior decorations, automobile, trains, ships, flat, tempered laminated glass for architechure,etc.
Characteristics
1. Double heating section can effectively reduce time for heating and running the big blower, so as to achieve the goal of saving energy and the capacity is almost two time of ordinary type.
2. The use of lower temperatures in the front heating furnace could cut down the bad reaction after the glass enter into the furnace.
3. Especially for the patterned and coated glass, the finished products owns high tempered quality with less breakage.
Parameters
Type |
Max.Glass Size(mm) |
Min.Glass Size(mm) |
Glass Thickness(mm) |
Capacity (m2 /h) |
Installation Power(kw) |
LDGS2003 |
2000×300 |
50×50 |
2.85-6 |
13 |
120 |
LDGS2506 |
2500×600 |
100×50 |
2.85-12 |
28 |
300 |
LDGS3209 |
3200×900 |
180×80 |
2.85-12 |
43 |
490 |
LDGS4012 |
4000×1250 |
250×100 |
2.85-15 |
112 |
690 |
LDGN3010 |
5000×1500 |
300×100 |
2.85-19 |
170 |
980 |
LDGN3010 |
5000×2400 |
300×300 |
4-19 |
275 |
1220 |
Remark
All sizes are based on millimeter and the capacity subjected to 5mm glass at 80% utilization and 100% end-product rate. The change of equipment configuration will be in accordance with the different of glass thickness range,it is depended on actual design.
