Passing Flat Glass Tempering Furnace

Passing Flat Glass Tempering Furnace thumbnail-1
Passing Flat Glass Tempering Furnace photo-1
US$ 50,000 - 100,000 MOQ: 1 Set
Key Specifications
Get Latest Price
Condition:
New
Machine Type:
Glass Tempering Furnace
Place of Origin:
Zhejiang, China
Contact Supplier Request Quote Chat Now
Haining Lidu Glass Machine Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai/Ningbo
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Condition New
Machine Type Glass Tempering Furnace
Place of Origin Zhejiang, China
Brand Name LIDU
Model Number LDGT2436
Voltage 220v-415v
Power(W) 300KVA
Dimension(L*W*H) 19800*3500*2000
Certification Other, CE, CE/ISO9001:2000
Warranty 1 year
After-sales Service Provided Engineers available to service machinery overseas

Specifications

1.Glass tempering furnace
2.Outstanding energy-saving
3.High production efficiency
4.Strong stability
5.CE certificat



Passing Flat Glass Tempering Furnace/ LDGT2436





Mainly in



High grade industrial instrumentation, lamp, appliance glass, small, size flat tempered glass, interior decorations, automobile, trains, ships, thin flat tempered laminated glass for architecture, and etc.





Characteristics



1. Separate the quenching and cooling section ,the time to use of high pressure blower reduces 70-80%,and the blower power reduce 50%.With a small blower for cooling ,the power consumption reduces 30%.



2. Air diffuser: cross-spread big &small aperture .Advantage :reduce spot



    Fan: large air flow & low wind pressure. Advantage: reduce noise, save energy.



3 .The blower is controlled with inverter completely, so that it can reduce power consumption.



4. Add special air diffuser for tempering for saving energy.



5. The heating uniformity and the heating rate inside the furnace is improved by advanced heating system.



6. With UPS system.





Passing Flat Glass Tempering Furnace



Passing Flat Glass Tempering Furnace

Passing Flat Glass Tempering Furnace



Passing Flat Glass Tempering Furnace









Parameters



 Type

Max.Glass Size

(mm)

Min.Glass Size

(mm)

Glass Thickness

(mm)

Capacity

 (m /h)

Installation Power

(kw)

LDGT1225

1250×2500

100×250

2.85-15

38

290

LDGT1525

1500×3660

100×300

2.85-15

45

350

LDGT1240

1200×4000

100×300

2.85-15

60

400

LDGT1540

1500×4000

100×300

2.85-15

72

520

LDGT1550

1500×5000

100×300

2.85-19

90

600

LDGT2036

2000×3600

100×300

4-19

87

570

LDGT2042

2000×4200

100×300

4-19

103

600

LDGT2436

2400×3600

300×300

4-19

103

600

LDGT2442

2400×4200

300×300

4-19

115

650

LDGT2450

2400×5000

300×300

4-19

145

780

LDGT2480

2400×8000

300×300

5-19

288

1230





Passing Flat Glass Tempering Furnace

Passing Flat Glass Tempering Furnace











LIDU Factory
