Density in Liquefied Petroleum Gas Tester

Density in Liquefied Petroleum Gas Tester thumbnail-1
Density in Liquefied Petroleum Gas Tester photo-1
US$ 2,000 - 5,300 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Hunan, China
Brand Name:
Friend
Model Number:
FDS-0201
Contact Supplier Request Quote Chat Now
Changsha Friend Experimental Analysis Instrument Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Guangzhou Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Hunan, China
Brand Name Friend
Model Number FDS-0201
Power Other, Electronic, 15W
Usage Auto Testing Machine

Specifications

density in Liquefied petroleum gas tester
ASTM D1657,ISO3993
easy to operate
high precision
HOT sale

  Scope
 liquefied petroleum gas density tester (pressure densitometer method) in accordance with the SH / T0221-92, ASTMD1657 and ISO3993 "liquefied petroleum gas and light hydrocarbons - Determination of density or relative density (pressure densitometer Act)" and other standard measurement of liquefied petroleum gas and light hydrocarbons. At the test temperature, vapor pressure (gauge pressure) is higher than the sample 1.4MPa should not use this instrument.
Features
1.three valves by 1Cr18Ni9Ti material can withstand 4Mpa pressure.
 2, made of transparent Plexiglas cylinder, both ends of the metal end plates and neoprene gasket seal.
3, bath by 1Cr18Ni9Ti material, electric heater installed in the bath and electric stirring device, automatic temperature control system, to meet the test temperature 15 ± 0.2 ℃ or 20 ± 0.2 ℃.
4, the temperature control device with digital display, responsive, accurate temperature control.
5, by a motor stirrer, a stirring shaft and the leaf, low noise and high efficiency.
Technical parameters
1, Power: 198-242V 49-51Hz
 2, stirring motor     a model:. YY     b power:. 15W     c speed:. 1250r / min
3, the heating power: 1000W
4, temperature control accuracy: 15 ± 0.2 ℃ or 20 ± 0.2 ℃
5, the cylinder under pressure:> 1.4Mpa



Technology

density in Liquefied petroleum gas tester









Packaging & Shipping
Packaging Detail: standard export case
Delivery Detail: 20 working days after receipt of the advance payment.

density in Liquefied petroleum gas testerdensity in Liquefied petroleum gas tester







Our Services

warranty: 12 month

Friend has always adhere to the alliance strategies with customer unit development, and integrate enterprise resource advantages,with the pursuit of excellence in product quality, innovative and pragmatic attitude to customer needs and to provide professional pre-sales,

after-sales service.

density in Liquefied petroleum gas tester

density in Liquefied petroleum gas tester

 density in Liquefied petroleum gas tester



Company Information

 Since the establish of Friend,it uphold the Western industrial civilization "artisan spirit" as the ideas, and constantly improve our products, and continuously improveour processes to meet market demand, and strive to create a new management models and new products to meet customer growing needs.

density in Liquefied petroleum gas testerdensity in Liquefied petroleum gas tester







Certifications

density in Liquefied petroleum gas tester









customers

density in Liquefied petroleum gas testerdensity in Liquefied petroleum gas tester





Related Products

CLICK----

FDT-1501

FDT-1531

FDS-0201

FDL-1201

FDY-0601



Standards

GB/T 1884

GB/T1884

SH/T0221

GB/T 8928

SH/T0068 ,ASTM D1122



Power supply

AC220V / 50Hz

AC220V / 50Hz

AC220V / 50Hz

AC220V / 50Hz

AC220V / 50Hz



Temperature range

 room temperature ~ 100 ℃

room temperature ~ 100 ℃



10 ~ 30 ℃

20 ℃



Temperature accuracy

± 0.2 ℃

± 0.2 ℃

15 ± 0.2 ℃ or 20 ± 0.2 ℃

± 0.5 ℃

± 0.2 ℃



heating power

 1800W

800W

1000W



electric heating tube



Input power

 1850W









Bath volume



Φ300 × 300mm







cylinder pressure

> 1.4Mpa
