High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay

High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-1
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-2
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-3
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-4
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-5
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay thumbnail-6
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-1
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-2
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-3
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-4
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-5
High Lumen 200W LED High Bay Lights,CE ROHS ,LED High Bay photo-6
US$ 100 - 230 MOQ: 50 Sets
Key Specifications
Get Latest Price
Light Source:
Fluorescent
Input Voltage(V):
100-277
Lamp Power(W):
150
Contact Supplier Request Quote Chat Now
Shenzhen Aroma Lighting Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shenzhen
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Light Source Fluorescent
Input Voltage(V) 100-277
Lamp Power(W) 150
Lamp Luminous Flux(lm) 18000
Lamp Luminous Efficiency(lm/w) 100
Color Temperature(CCT) Pure White
Working Temperature(℃) -20, 45
Working Lifetime(Hour) 35000
Lamp Body Material Aluminum Alloy
IP Rating IP54
Certification CCC, CE, ETL, LVD, VDE
Brand Name ARM
Base Type E17
Place of Origin Guangdong, China
Model Number ARM-HB-0411M20-200W

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Explosive view

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Product Description



----MEAN WELL Driver

----  Bridgelux

----Input: 100-277V

----Power: 100W/120W/150W/200W

----Warranty>3years

----CRI>70

----PF>95

----IP Rate: IP54

----Beam Angle 45°/60°/90°/120°

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Dimension

 High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Technical Data

Item No.

 200W

Input Voltage

AC 100-277V / 50-60Hz

Working Voltage

DC30-36V

LED Type

SMD LED

Color Temperature (CCT)

2700-3500K, 4500-5500K, 6000-7000K

Beam Angle of Reflector (Optional)

45°/ 90°/120°

Color Rendering Index (CRI)

>70

Lamp Efficiency

>90%

LED Luminous Efficiency

100-105lm/w

Power Factor (PF)

>0.95

Total Harmonic Distortion (THD)

≤9%

Illuminance Uniformity

>0.7

Light Distribution

Symmetrical / Round Light Area

LED Junction Temperature

≤70℃

Waterproof Performance

IP 54

Average Lifespan

35,000hrs

Net Weight (without Reflector)

7.2kg

Certificate

CE / ROHS / SAA / UL



High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Optional Lamp Cover

 High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay





Photometric Diagram

 High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Packing Information



High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Application



LED High Bay is more and more popular for indoor lighting, they can use widely

in these places below:Factory, Warehouse, GYM, Supermarket, etc.

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Installation

High lumen 200W LED High Bay Lights,CE ROHS ,LED high bay



Step 1: Connect the metal ring to the LED transformer cover, and tighten the screw, then install the LED high bay light to the right position.



Step 2: Loosen the 4 pieces screws in the Heat Sink, then fasten the screws after put the AL reflector into the right position.



Step 3: Connect LED high bay light to the power and lighten it, please distinguish the wires correctly.



            1. Brown: L (Live wire)



             2. Blue: N (Null wire)



             3. Yellow: G (Ground wire)



Warning:



Please check the components before Installation, and read the User Manual before installation.



   1. The installation must be implemented by qualified electrician.



   2. Sulphides, corrosive and dissolve chemicals will damage the Lamp fixture, even the LED will be broken.



   3. Working temperature: -20℃-45℃, the lifespan will be shorten if the working temperature beyond this range.



   4. Please ensure the power is off, and the lamp fixture is cooled down sufficiently before installation.



   5. Please ventilate the LED high bay light, and comply with local Fire Precautions Legislation.



AROMA Instruction



Aroma Technology Co.,Ltd was established in 2014, as a professional LED lighting manufacturers and LED lighting suppliers in China, we are specialized in research, development, manufacture and sales of LED panel light, LED down light, led floodlight and so on. Currently there are over 200 employees and a fabrication area of more than 6,000 square meters.



Aroma Technology Co.,Ltd is also a company focus on commercial lighting and outdoor lighting. all of our led panel light are with CE approval and ROHS compliance, part of the products gain FCC,PSE certification, and UL is pending .



As excellent quality, we provide all of our led panel light 3 years warranty.
