Specifications
1.cable shredder2.99.99% copper purity
3.Dry type in whole process
4.Fully automatic separation
5.CE,BV,ISO
CE and BV Certified Cable Shredder Recycling System
cable shredder recycling system introduction:
cable shredder recycling system is designed by us in recycling autowire,communicate cable and other mixed copper wire/cable into copper granules and plastic granules in eco-friendly way.
cable shredder recycling system technical parameters:
|
Model Item |
AMS-600 |
Power |
31KW |
Capacity |
300-400kg/h |
Dimension |
L2830*W2000*H2800mm |
Weight |
2800kg |
Packing Dimension |
L2900*W2100*H2000mm |
Packing Weight |
2900kg |
cable shredder recycling system advantages:
- With CE and BV certified.
- With latest technology and unique design,which has greatly etter effect than the old model
- The material of the waste wire can be telephone wire, household electric wire, automotive wire and cables,diameter should be within 20 mm. Just needing 1-2 workers to operate, labour-saving, small land occupancy and investment
- Combines many processions into one, including crushing, conveying, dust collecting, separating process. It can recycle both the copper granule and PVC plastic.
- High recycling rate of 99.99%, When processing the scrap/waste copper wire/cables, it has no dust, no environmental pollution
- No need water during the whole process
- Equipped with PLC control system and air separation system
- Voltage can be customized according to your local power supply.
- Energy conservation up to 15%
cable shredder recycling system process:
1.Crushing process
Put waste copper/ cable into crusher to make plastic skin and copper separate completely
2. Conveying and dust-collecting
After crushing, the crushed material (mixture of copper and plastic) will be conveyed to the separator, during which procedure the plastic granules (including fiber, rope, ordust,etc. ) are cleaned by the dust cleaner.
3. Separating process
The vibrating separator consists of separating board, amplitude adjustable device, and speed adjustable motor,etc. It is used to separate plastic and copper.
4. Copper-collecting and copper clad recrushing
There are two discharging holes respectively for copper and plastic, if there are any copper clad, they need to be recrushed.
5. All the units are installed on the underbed to form a whole plant, very easy for
transport. The machine is well adjusted before shipping, so the customer only needs to connect it to the power supply before production.
cable shredder recycling system packing information:
Using good wooden cases(plywood) special for shipment!
