2013 new type with CE mini oil press machine
1.This machine has simple structure and it is easy to operate.
2.It has high oil extraction rate ,and the oil is of fine quality.
3.This machine is well designed so it could save electrcity, and it makes low noise during the process of operation,which is good for the health of the people who works around the machine.
* The Specification of the mini oil press machine:
- Simple,convenient,energy saving,competitive price.
- This oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc
- final oil is high quality, good smell, and high yield rate.
- It uses high carbon steel, which through high frequency quenching and heat-resisting, it is high hardness and strength, good abrasion resistance that suit for high temperature and high pressure continous working, all this had improved the service life of the oil press for decades.
Model |
Capacity (T/D 24 hours) |
Power (KW) |
Outside Size(MM) |
Weight(KG) |
AMS-68 |
1-1.5 |
5.5 |
900*530*760 |
160 |
AMS-80 |
2-3 |
5.5 |
1810*560*735 |
370 |
AMS-100 |
3-5 |
7.5 |
1910*610*765 |
480 |
AMS-120 |
5-6 |
11 |
2060*610*760 |
650 |
AMS-120C |
7-8 |
15 |
2100*700* 770 |
650 |
AMS-130 |
9-12 |
18.5 |
2280*700* 770 |
850 |
AMS-160 |
13-18 |
22 |
2400*700* 780 |
1050 |
Screw mini oil press machine Structure
Screw oil press is a popular type of the mini oil press machine, mainly composed of feeder, gearbox, pressing chamber and oil receiver. Some screw oil press machines are equipped with electric motors as required. Pressing chamber is the key part which contains a pressing cage and a screw shaft rotating in the cage. An electric cabinet is also necessary to control the whole working procedure.
AMS mini oil press machine Features
Different from the automatic screw oil press, this screw oil press has its own features and markets.
1.Made of high quality steel, wear-resistant and easy to clean.
2.With the properly designed pressing chamber, the increased pressure in the chamber highly improves working efficiency.
Why Choose AMS Screw mini oil press machine?
1.Wide application: ideal machine for pressing various oil seeds, such as peanut, soybean, sesame, flax seed, etc;
2.High oil yield : the oil output is 35% - 50% higher than common oil press.
3.Low residual: the oil residual in cake is only about 5%.
4.Little land occupancy: only 10-20 square meter is enough.
Tips
Make full use of your abundant oil seeds and start a low investment business, don't miss our screw oil press.
