Screw Oil press machine/oil mill/oil expeller
- 300 Set / Sets per Month
- Qingdao port
- T/T Credit Card
- used for stone pe-250x400 quartz small jaw crushers
- low comsuption mini rock diesel engine jaw crusher
- china manufacturer provide used jaw crusher price
- high efficiency pe 400 x 600 old mini jaw crusher for sale
- manufacturer provide toggle platepe 150x250 jaw crusher machine
- pe 400x600 mobile jaw crusher price with spare parts
Product Details
Condition: | New | Usage: | Peanut Oil | Type: | Other, Cold & Hot Pressing Machine |
Automatic Grade: | Automatic | Production Capacity: | High | Place of Origin: | Henan, China |
Brand Name: | AMS | Model Number: | AMS-80 | Voltage: | 380V |
Power(W): | 7.5KW | Dimension(L*W*H): | 1910*610*765mm | Weight: | 480KGS |
Certification: | CE | After-sales Service Provided: | Engineers available to service machinery overseas |
Product Description
Screw Oil press machine/oil mill/oil expeller
Oil expeller Materials:
The equipment oil expeller can be used to extract vegetable oil by continuously pressing
peanuts, rapeseeds, soybeans,castor oil plant, sesame seeds, benne seeds, palm seeds, sunflower seeds, cotton seeds, tea seeds, tung seeds and etc.
* The Specification of the soybean oil expeller:
- Simple,convenient,energy saving,competitive price.
- This oil press machine is composed of feeder, gearbox, pressing cage, screw shaft and machine stand etc
- final oil is high quality, good smell, and high yield rate.
- It uses high carbon steel, which through high frequency quenching and heat-resisting, it is high hardness and strength, good abrasion resistance that suit for high temperature and high pressure continous working, all this had improved the service life of the oil press for decades.
Model | Capacity (T/D 24 hours) | Power (KW) | Outside Size(MM) | Weight(KG) |
AMS-68 | 1-1.5 | 5.5 | 900*530*760 | 160 |
AMS-80 | 2-3 | 5.5 | 1810*560*735 | 370 |
AMS-100 | 3-5 | 7.5 | 1910*610*765 | 480 |
AMS-120 | 5-6 | 11 | 2060*610*760 | 650 |
AMS-120C | 7-8 | 15 | 2100*700* 770 | 650 |
AMS-130 | 9-12 | 18.5 | 2280*700* 770 | 850 |
AMS-160 | 13-18 | 22 | 2400*700* 780 | 1050 |
Screw Oil Expeller Structure
Screw oil press is a popular type of oil expeller, mainly composed of feeder, gearbox, pressing chamber and oil receiver. Some screw oil press machines are equipped with electric motors as required. Pressing chamber is the key part which contains a pressing cage and a screw shaft rotating in the cage. An electric cabinet is also necessary to control the whole working procedure.
AMS Screw Oil Expeller Features
Different from the automatic screw oil press, this screw oil press has its own features and markets.
1.Made of high quality steel, wear-resistant and easy to clean.
2.With the properly designed pressing chamber, the increased pressure in the chamber highly improves working efficiency.
Why Choose AMS Screw Oil Expeller?
1.Wide application: ideal machine for pressing various oil seeds, such as peanut, soybean, sesame, flax seed, etc;
2.High oil yield : the oil output is 35% - 50% higher than common oil press.
3.Low residual: the oil residual in cake is only about 5%.
4.Little land occupancy: only 10-20 square meter is enough.
Tips
Make full use of your abundant oil seeds and start a low investment business, don't miss our screw oil press.
* The technology of the peanut oil expeller
Model | Capacity (T/D 24 hours) | Power (KW) | Outside Size(MM) | Weight(KG) |
AMS-68 | 1-1.5 | 5.5 | 880*440*765 | 140 |
AMS-80 | 2-3 | 5.5 | 1320*440*1040 | 330 |
AMS-95 | 3-5 | 7.5 | 1610*615*1260 | 420 |
AMS-120 | 5-6 | 11 | 1770*610*1300 | 680 |
AMS-120C | 7-8 | 15 | 1870*750*1300 | 750 |
AMS-130 | 9-12 | 18.5 | 1980*700*1460 | 820 |
AMS-160 | 13-18 | 22 | 2020*700* 780 | 980 |
The spare parts of the peanut oil expeller machine The complete processing of the peanut oil expeller
The production room of the peanut oil expeller
The packing and delivery of the peanut oil expeller
