2014 new designed single chamber vacuum packing Machine

Specifications

single Chamber Vacuum Packing Machine,Stainless steel shell and control board with touching button adopted.

Vacuum packaging machine

product introduction:

1>Our company is only company which research and development  LCD version vacuum packaging machine ,this machine has LCD ,it can Chinese-english switchable,operation and debugging, maintaining simple ,failure warning etc.automatic function,replace  provious generation computer version vacuum packing machine.

 2>this machine small volume ,save power ,sucking air in short time ,is suitable for packing small type goods ,such as meat or fish, vegetable , bread or fruit and so on.The packed products can be prevented from oxidation, going mould, insects or getting damp, thus can be kept fresh in a prolonged storage period

3>Operation

DZ series single chambers vacuum (aeration) packaging machine, As long as you press the vacuum case's lid, the machine will automatically complete the orderly assumed processes of vacuum extraction or aerate the orderly assumed processes of vacuum extraction or aerate the inner gas,sealing, printing, cooling and aeration.

Technical Parameters:

Model	DZ400/2E	DZ500/2E
Voltage	AC 220V/50HZ,110V/60HZ
Vacuum Pump Power	750W	1500W
Sealing Power	500W	750W
Ultimate vacuum pressure	1 Kpa
No.of sealing bars for each chamber	2
Chamber dimension L*W*H	430*420*75mm	530*520*75mm
Sealing Length	400mm	500mm
Sealing width	10mm	10mm
Vacuum pump rate	20m³/h
Material of vacuum chamber	Stainless steel
Machine dimension L*W*H	540*500*950mm	580*630*1000mm
Net Weight	110kgs	125kgs

machine picture(vertical LCD type.table type and double chamber vacuum packing machine )

 vertical LCD type

table type

double chamber vacuum packing machine

more details pls come back.
