Stainless Steel Pneumatic Liquid Filling Machine

horizontal pneumatic liquid filling machine (Single Head / double-headed)

Main use:

 Single Head / double-headed horizontal pneumatic liquid filling machine are for filling liquid in daily chemical industry, pharmaceutical industry, food industry ~

Principle features:

1, the model filling machine design is reasonable, model compact, convenient operation, pneumatic part of Germany FESTO and Japan have adopted SMC pneumatic components;

2, cylinder piston and cylinder are made of Teflon and stainless steel material conforms to GMP requirements;

3, filling volume and filling speed can be arbitrarily adjusted, filling accuracy is high;

4, filling bulkhead use of anti-drip, anti-filling drawing and lifting devices;

5, the filling machine can be modified according to customer demand to become long, explosion-proof type, overflow-type filling system.

 Technical parameters:

Single head Filling speed :10-30 bottles / min

Double head filling speed :20-80 bottles / min

Filling precision: ± 1%

Power: 220/110V   50/60Hz

Pressure :0.4-0 .6 Mpa

Filling capacity:5-60ml 10-125ml 25-250ml 50-500ml 100-1000ml 250-2500ml 500-5000ml

The diameter of bottles : more than 4 MM

Apply to : any height bottle

Filling accuracy :99%

machine image:
