Animal Feed Pellet Making Machine
* Introduction of the animal feed pellet making machine
The Animal Feed pellet making machine for poultry can adjust the raw material moisture to ensure good-quality pellets. Then the suitable raw material is sent to pelletizing chamber.
When the roller is moving in the pelletizing chamber, it makes the raw material inletting the holes of ring die and form the pellets. Several paring knives cut the pellets to size as they are extruded from the drum, after which they fall through the bottom discharge chute into a container ready for use.
1. The fuel pellets are widely used for home and industrial heating and electricity-generating in large power plants.
2. The feed pellets are popular with poultry-breed, fish and other aquatics culture. Feed Pelletizing has been, and continues to be, a popular processing technique in feed manufacturing.
Size range of making feed pellets: 1.5mm, 2.0mm, 2.5mm, 3.0mm, 3.5mm, 4.0mm
Quality Guarantee: 2 years guarantee for main body
Extensive range of pellet plant ancillary machines and spares for your choice
Features of the animal feed pellet making machine:
Firstly, the material is transferred into the conditioner by the movable screw feeder. Then the conditioner can make different materials fully mixed.
What’s more, it can adjust the raw material moisture to ensure good quality pellets. Then the suitable raw material is sent to pelletizing chamber.
When the roller is moving in the pelletizing chamber, it makes the raw material inletting the holes of ring die and form the pellets.
Several paring knives cut the pellets to size as they are extruded from the drum, after which they fall through the bottom discharge chute into a container ready for use.
Advantages of ring die pellet mill/ animal feed pellet making machine.
The animal feed pellet making machine is designed more advanced and complex than flat die pellet mill.There are also two main advantages of ring die pellet mills.
1. Ring die pellet mill generate less wear and tear when pelletizing.
2. Ring die pellet mill are more energy efficient than the flat die pellet mill.
3. These factors have led to ring die pellet mills being adopted in most large scale pellet production lines.
4. The ring die pellet mill will be much easier to produce high quality pellets and high efficiency output.
5. Ring die pellet mill for feed pellets does not need any external force to feed the material.As the grain material like wheat, corns, etc.
is heavy enough to enter the pelletizing chamber automatically and smoothly.
6. The advanced conditioner ensures the conditioning time>150 seconds, making the material cooked sufficiently so as to be helpful for the quality of pellets.
7. Double or three layers jacketed conditioners can be installed to meet special needs of aquatic feed.
The technology date of the animal feed pellet making machine
| Model | SZLH320 | SZLH350 | SZLH400 | SZLH420 | SZLH508 |
| Capacity | 2-5T/H | 1.5-8T/H | 2-10T/H | 3-12T/H | 4-20T/H |
| Main Motor Power | 37KW | 55KW | 75/90KW | 110KW | 132/160KW |
| Screw Feeder Power | 0.55KW | 0.75KW | 0.75KW | 1.5KW | 1.5KW |
| Conditioner Power | 2.2KW | 2.2KW | 2.2KW | 5.5KW | 7.5KW |
| Ring die inner diameter | 320mm | 350mm | 400mm | 420mm | 508mm |
| Ring die rotational speed | 305PRM | 336PRM | 307PRM | 287PRM | 287PRM |
| Roller outer diameter | 140mm | 165mm | 190mm | 206mm | / |
| Dimension | 2300*1000*2100 mm | 3200*1100*1700 mm | 3200*1300*1900 mm | 3500*1300*2800 mm |
3500*1500*2900 mm |
The pictures of the animal feed pellet making machine
The roller and ring die of the animal feed pellet making machine :
The loading and delivery of the animal feed pellet making machine:
The production site of the animal feed pellet making machine plant:
