oil cake Feed Pellet Mill
I. Brief introduction of the oil cake feed pellet mill:
1. Flat die oil cake feed pellet mill can make all kinds of solid grain to be small pellet feed for animals like fish, shrimps, chicken, rabbit, horses, goats, etc, or you can make bedding pellets for animal stalls from cardboard. It can also make all kinds of saw dust, paddy straw, sunflower stalk, forestry wastes, wood chipsand many other wastes into wood pellets to be used as fuels.
2. The utility model is especially suitable for feeders, farmers as a processing machine of grains and feedings3. This series of feed particle machine is a small device, it is designed for rural breeding, specialized households, small and medium-sized feed mill, Livestock farm, and it can process a variety of feed
pellets of different diameters.
4. Aircraft critical components using special materials and special processing, such as pressure rollers use a vacuum furnace imports from Germany for surface hardening, and powerful shot peening, surface hardness up to HRC62 good wear resistance, long life, mold plate the special design principle, uniform and reasonable layout of the die hole, after surface hardening and shot peening, good wear resistance, and high-capacity, uniform material, long life.
2. Features of the oil cake feed pellet mill :
1. The flat die pellet mills are easier to clean than the ring die pellet mill.
2. Able to change die and roller faster and easily.
3. Small and lightweight, making small-scale production possible.
4. Visibility. It is possible to view into the chamber when pelletizing, you can solve any problem timely
5. The main features of the feed pellet mill: high energy efficiency, reasonable structure, work reliable, wide adaptability, elegant, easy to clean, easy to operate.
Oil Cake Feed Pellets Market Prospect
With increasing emphasis on cost reduction of industrial processes, apart from agro-industrial residues, oil cakes could be ideal source of feed pellets pelletizing processes. Oil cakes are rich in fiber, protein and energy contents, thus they offer potential benefits when used as animal feed, especially for ruminants and fish in animal and poultry breeding industry. All in all, oil cake feed pellets have broad market prospects. If you consider investing in this field for more profits, please feel at ease because it’s really a novel and potential market valuable to explore.
Oil Cake Pelletizing Process
Generally, a whole oil cake pelletizing process consists of the following parts: oil cake waste collecting, crushing, mixing, pelletizing, cooling and screening, packing. And the whole process is highly automatically controlled. In the pelletizing process, pellet mill is the heart of the whole pellet production line. So you need choose proper pellet machinery according to your production requirements, taking the following factors into consideration like capacity, output, demand, cost.
Specification of the oil cake feed pellet mill
electricity power models:
Specification |
Capacity (kg/h) |
Power (kw) |
Density (g/m3) |
Moisture (%) |
Dimension (mm) |
Weight (kg) |
AMSKLS-150 |
110-180 |
4 |
1.1-1.4 |
13-18 |
910*400*890 |
185 |
AMSKLS-200 |
200-300 |
7.5 |
1.1-1.4 |
13-18 |
1000*430*950 |
230 |
AMSKLS-230 |
300-400 |
11 |
1.1-1.4 |
13-18 |
1140*470*970 |
320 |
AMSKLS-260 |
400-600 |
15 |
1.1-1.4 |
13-18 |
1220*500*1070 |
360 |
AMSKLS-300 |
600-800 |
22 |
1.1-1.4 |
13-18 |
1220*600*1000 |
450 |
AMSKLS-360 |
700-900 |
22 |
1.1-1.4 |
13-18 |
1220*600*1000 |
500 |
AMSKLS-400 |
900-1100 |
30 |
1.1-1.4 |
13-21 |
1320*600*1050 |
585 |
Diesel power models:
Model No |
Capacity (kg/h) |
Power |
Die Diameter |
Weight |
|
Sawdust |
Feedstuff |
|
|||
AMSPLM-120A |
50-70 |
70-100 |
8HP |
120 mm |
100 kg |
AMSPLM-150A |
80-100 |
100-150 |
8HP |
120 mm |
150 kg |
AMSPLM-200A |
100-150 |
250-350 |
15HP |
200 mm |
250 kg |
AMSPLM-230A |
150-180 |
300-400 |
22HP |
230 mm |
380 kg |
AMSPLM-260A |
180-230 |
400-600 |
30HP |
260 mm |
500 kg |
AMSPLM-300A |
250-300 |
600-800 |
55HP |
300 mm |
650 kg |
AMSPLM-360A |
300-400 |
700-900 |
55HP |
360 mm |
750 kg |
AMSPLM-400A |
400-600 |
900-1000 |
55HP |
400 mm |
850 kg |
Finished pellets of the oil cake feed pellet mill
Size range of making feed pellets - 2.5mm, 3mm, 4mm, 6mm, 8mm
Quality guarantee - 2 years guarantee for main body.
The spare parts of the oil cake feed pellet mill
The Application of the oil cake feed pellet mill
* Suitable for processing various kinds of solid grain into small feed pellets for animals like cattle,
cow, chicken, rabbit, pig, etc.
* Suitable for making bedding pellets for animal stalls from cardboard.
* Also suitable for processing biomass material and many other agro wastes into wood pellets for
green fuel.
The packing and delivery of the oil cake feed pellet mill
