Best service JZC 250/350/500 concrete mixer0086 13903817193

Specifications

best service jzc series concrete mixer
Easy Operation and high efficiency and quality
Low power and price
ISO, CE certifica

 JZC series Concrete Mixer

I: Introduction of jzc series concrete mixer

JZC series concrete mixer are self-loading which can mix plastic and half dry hard concrete. The machine mixes when the double-cone mixer drum rotates clockwise and discharges when it rotates reversally. The mixer drum is driven by the ring gear. It has strong points such as reliable rotation, low noise and energy consumption, compact structure, smooth running. Moreover easy operation, high quality mix and production efficiency are also its advantages. it is the ideal machines for construction sits, road, bridge project, hydroelectric power and small and medium concrete components factory.

II.Main Parameter of  jzc series concrete mixer

Model	JZC250	JZC350	JZC500
Discharging capacity	250L	350L	500L
Charging capacity	350L	500L	750L
Production capacity	6-8m3/h	10-14m3/h	18-20m3/h
Mixer canister rev speed	17r/min	14r/min	13r/min
Max aggregate diamter	60mm	60mm	60-80mm
stiring motor	4kw	5.5kw	11kw
lifting motor	4kw	5.5kw	5.5kw
pump power	0.55kw	0.55kw	0.75kw
max towing velocity	20km/h	20km/h	20kg/h
size	2260*1990*2750mm	2766*2140*3000mm	5226*2200*5460mm
weight	1300kg	1950kg	3100kg



III. Image of diesel jzc series concrete mixer



IV: Service of  jzc series  concrete mixer

 Befor-sale services: we guide clients to choose the best and suitable mchine, provide the advance, energy-saving and practical technological process. At the same time, we are responsible for the planing and design the machine

Sale service: Products must be inspected strictly before being sold,clients are invited to simulate and test machine on the spot; in accordance with the agreements stipulated in the contract, and then we are arrange delivery the machine

After-sale service: Our company will free offer the professional engineer to guide installation,training how to operation this machine. We are confrim that our clients can use the machine well and bring more and more befit to them.

We are design and product machines according to the speciall requirement by clients.

Guarantee period: 1 year
