Specifications
JS series concrete mixer:1. ISO9001:2000 certified
2. Auto operation by PLC
3. Excellent mixing performance
Hot-selling good performance JS series concrete mixer
AMISY JS series concrete mixer has double horizontal mixing axles, which can produce, plasticity concrete, lightaggregate concrete and variety of mortar. They are applicable to the normal construction projects, road/bridge site, or small or medium size concrete component factories. JS series concrete mixer adopt new type of aggregate feeding device and mixing blades connection style, that improves the mixer stability, mixing quality, mixing speed, productivity, and keep long-term service life.
JS series concrete mixer simple concrete mixer products, simple concrete mixer, can be working independently, which also be the best choice for old Concrete Batching Plant replacement.
Technical features of JS series cement mixers
AMISY JS series cementmixershas double horizontal mixing axles, which can produce plasticity concrete, lightaggregate concrete and variety of mortar. They are applicable to the normal construction projects, road/bridge site, or small or medium size concrete component factories.
JS series concrete mixer adopt new type of aggregate feeding device and mixing blades connection style, that improves the mixer stability, mixing quality, mixing speed, productivity, and keep long-term service life.
Item parameter model |
JS500 |
JS750 |
JS1000 |
JS1500 |
|
Discharge capacity(L) |
500 |
750 |
1000 |
1500 |
|
Feeding capacity(L) |
800 |
1200 |
1600 |
2400 |
|
Max production rate |
≥25m³/h |
≥37.5m³/h |
≥50m³/h |
≥75m³/h |
|
Maximum aggregate sizes(pebble/gravel) |
80mm/60mm |
80mm/60mm |
80mm/60mm |
80mm/60mm |
|
Working circle |
60s |
60s |
60s |
60s |
|
Mixing blade |
rational speed |
35r/min |
31r/min |
25.5r/min |
25.5r/min |
|
quantity |
2×7 |
2×7 |
2×8 |
2×10 |
Mixing motor |
Type |
Y180M-4 |
Y200L-4 |
Y225S-4 |
Y225M-4 |
|
power(kw) |
18.5 |
30 |
37 |
45 |
Hoist motor |
Type |
YEZ1325-4-B5 |
YEZ132M-4-B5 |
YEZ160S-4 |
YEZ180L-4 |
|
power(kw) |
5.5 |
7.5 |
11 |
18.5 |
Pump motor |
Type |
50DWB20-8A |
65DWB35-8A |
KQW65-1001 |
KQW65-1001 |
|
power(kw) |
0.75 |
1.1 |
3 |
3 |
Size |
transporting status(mm) |
3050*2300*2680 |
3650*2600*2890 |
4640*2250*2250 |
5068*2250*2440 |
|
working status(mm) |
4461*3050*5225 |
4951*3650*6225 |
8765*3436*9540 |
9645*9436*9700 |
Total weight(kg) |
4000 |
5500 |
8700 |
11130 |
|
Discharge height(mm) |
1500 |
1600 |
2700/3800 |
3800 |
|
Speed of Hopper lifting (m/min) |
18 |
18 |
21.9 |
23 |
|
