Smooth Surface HDPE Geomembrane

Smooth Surface HDPE Geomembrane thumbnail-1
Smooth Surface HDPE Geomembrane thumbnail-2
Smooth Surface HDPE Geomembrane thumbnail-3
Smooth Surface HDPE Geomembrane thumbnail-4
Smooth Surface HDPE Geomembrane thumbnail-5
Smooth Surface HDPE Geomembrane thumbnail-6
Smooth Surface HDPE Geomembrane photo-1
Smooth Surface HDPE Geomembrane photo-2
Smooth Surface HDPE Geomembrane photo-3
Smooth Surface HDPE Geomembrane photo-4
Smooth Surface HDPE Geomembrane photo-5
Smooth Surface HDPE Geomembrane photo-6
US$ 0.29 - 2.99 MOQ: 1000 Square Meters
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
prettylion
Model Number:
0.2mm to 4.0mm
Contact Supplier Request Quote Chat Now
Taian Pretty Lion Light Industrial Products Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
QINGDAO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shandong, China
Brand Name prettylion
Model Number 0.2mm to 4.0mm
Material EVA, HDPE, LDPE, LLDPE, PVC



smooth surface HDPE geomembrane is made from high quality HDPE polyethylene, use the most advanced equipments which take the three-layer co-excursion blown film line. All the products comply with GRI Standard, ASTM, CJ/T234-2006 and GB/T17643-1998. All sizes are available. Smooth/ Textured surface HDPE: Thickness: 0.25-4.00mm, the max width can be 7 meters which the largest product line in China.

Property:

Impervious performance: Water vapor permeability coefficient K≤1.0× 10-13g.cm/(cm2.s.pa)
High strength: Break Tensile strength≥28MPa
Life time: The materials can be used for hundred years
Cold tolerance: Embrittlement temperature -66℃~77℃
Corrosion resistant: Withstand the corrosion of more than 80 kinds of strong acid, strong alkali
Harmless: no harm to human beings, no pollution to the environment, wide application in the project of drinking
Better economic profitability: low in cost, less investment
Good weld ability: High weld strength







Smooth surface HDPE geomembrane

Textured surface HDPE geomembrane





Application:
All kinds of environmental protection projects, such as landfill, sewage treatment, petrochemical, metallurgical
Water conservancy projects, such as reservoirs, dams, rivers, and lakes
Subway, tunnel, underground warehouse
Landscape engineering: Manmade lakes, scenic spotsConstruction market and other waterproof engineering


Dreg fields of Panzhihua Titanium Industry Park

Waterproof project for Landfill of Heba Town Datong Lake area







Advanced production line

Advanced production line

Ultra-width HDPE geomembrane



Smooth HDPE geomembrane technology property index

No

Property

Value

0.75mm

1.00mm

1.25mm

1.50mm

2.00mm

2.50mm

3.00mm

1

Density G/CM3

0.939

2

Tensile properties

















Strength at yield, N/mm

11

15

18

22

29

37

44



Break at yield, N/mm

20

27

33

40

53

67

80



Elongation at yield, %

12



Elongation at break, %

700

3

Right angle tear strength, N

93

125

156

187

249

311

374

4

Puncture strength, N

240

320

400

480

640

800

960

5

Stress crack resistance using notched constant tensile load, H

300

6

Carbon Black

















Carbon Black Content of a %

2.0-3.0

7

OIT (Oxidation induction time)

















Standard OIT,MIN;
or

100



Pressure OIT,MIN

400

8

85℃ Oven ageing test(the minimum average value)

















Baking 90D later,Reserved standard OIT %; or

55



Baking 90D later,Reserved Pressure OIT%

80

9

Protection strength from UVA

















Irradiate with UVA after 1600H,Reserved Standard OIT%;or

50



Irradiate with UVA after 1600H,Reserved pressure OIT%

50

10

’-70°C Embrittlement of low-temperature impact

Passed

11

coefficient of permeability of water steam G.CM/(CM2.S.PA)

≤1.0*10-13

12

Dimensional Stability (%)

±2



Textured HDPE geomembrane technology property index

No

Property

Value

0.80mm

1.00mm

1.25mm

1.50mm

2.00mm

2.50mm

3.00mm

1

Density G/CM3

0.939

2

Crude height,MM

0.25

3

Tensile properties

















Strength at yield,N/MM



15

18

22

29

37

44



Strength at break,N/MM



10

13

16

21

26

32



Elongation at yield,%

12



Elongation at break,%

100

4

Right angle tear strength,N



125

156

187

249

311

374

5

Puncture strength,N



267

333

400

534

667

800

6

Stress crack resistance using Notched Constant tensile load,H

300

7

Carbon black

















Carbon black content of a %

2.0-3.0



Carbon black dispersion,(10 views)

9 out of 10 views should belong to grade 1 or 2, Grade 3 should not more than once

8

OIT (Oxidation induction time)

















Standard OIT,MIN; or

100



Pressure OIT,MIN

400

9

85℃ oven ageing test(the minimum average value)

















Baking 90D later,Reserved standard OIT %;or

55



Baking 90D later,Reserved Pressure OIT%

80

10

Protection strength from UVA

















Irradiate with UVA after 1600H,Reserved Standard OIT%;or

50



Irradiate with UVA after 1600H,Reserved pressure OIT%

50

11

’-70°C Embrittlement of low-temperature impact

Passed

12

coefficient of permeability of water steam G.CM/(CM2.S.PA)

≤1.0*10-13

13

Dimensional Stability (%)

±2















 Smooth Surface HDPE geomembraneSmooth Surface HDPE geomembraneSmooth Surface HDPE geomembraneSmooth Surface HDPE geomembraneSmooth Surface HDPE geomembrane
