hdpe geomembrane for landfill site
Smooth High Density Polyethylene Geomembrane
Specifications:
Width:2000-7000mm Thickness:0.3-3.0mm implementation of the standards: GM-13 (CJ/T 234-2006)
Main items and indicators:
Use and description:Pretty Lion brand of high quality polyethylene HDPE Geomembrane resins, is made by the three co-extrusion technology.
Features: Good physical and mechanical properties, high tear strength, good deformation adaptability, resistance to puncture, anti-aging, anti-UV, anti-oil, anti-salt, anti-acid and alkali, corrosion resistance, high and low tempreture resistance, non-toxic, long service life. Good effects of waterproof, drainage, anti-seepage and moistureproof. Complete specifications, width and thickness. Low cost and simple construction.
Application:
- 1. Environmental protection, sanitation (such as solid waste landfills, sewage treatment plants, power plants regulate pools, industrial, hospital solid waste, etc.)
- 2. Conservancy (such as rivers, lakes and reservoirs dam seepage, lost circulation, strengthening, drainage of seepage, vertical heart wall, slope protection, etc.)
- 3. Municipal works (subway, underground engineering building, green roof, roof garden seepage, sewage pipe lining, etc.)
- 4. Garden (artificial lake, river, reservoir, golf course ponds substrate, slope protection, green lawn water moisture, etc.)
- 5. Petrochemical (chemical plants, oil refineries, gas station storage tanks impervious, chemical reactor, settling tank lining, etc.)
- 6. Mining (washing, the heap leaching pool, the ash-field, dissolution, the precipitation, the yard, the substrates of tailings seepage, etc.)
- 7. Transport facilities (road base reinforcement, Subway, Culvert seepage)
- 8. Agriculture (channel, diversion canal, reservoir, reference pool, water storage pond, irrigation systerm seepage)
- 9. Aquaculture (intensive, factory farming pond, fish ponds, shrimp ponds lining, sea cucumber circle slope protection, etc.)
- 10. Salt (salt crystal pool, brine pool thatch cover, salt membrane, plastic thatch film of salt pond)
-
Item
Index
Thickness, mm
0.30
0.50
0.75
1.00
1.25
1.50
2.00
2.50
3.00
Density, g/cm3
0.940
Yield strength (MD/CD), ≥N/mm
3
5
8
11
13
16
22
26
33
Break strength
(MD/CD), ≥N/mm
5
8
12
17
20
24
34
40
51
Yield elongation
(MD/CD), ≥%
/
/
/
11
Break elongation
(MD/CD), ≥%
450
Right angle tear strength (MD/CD), ≥N
24
40
60
80
100
120
160
200
240
Puncture-resistant strength, ≥N
51
85
125
170
200
250
340
400
500
Carbon black content, %
2.0-3.0
Environmental Smooth High Density Polyethylene Geomembrane (GH-2SType)
Item
Index
Thickness, mm
0.75
1.00
1.25
1.50
2.00
2.50
3.00
Density, g/cm3
0.940
Yield strength (MD/CD), ≥N/mm
11
15
18
22
29
37
44
Break strength (MD/CD), ≥N/mm
20
27
33
40
53
67
80
Yield elongation (MD/CD), ≥%
12
Break elongation (MD/CD), ≥%
700
Right angle tear strength (MD/CD), ≥N
93
125
160
190
250
315
375
Puncture-resistant strength, ≥N
240
320
400
480
640
800
960
Environmental stress cracking time
(single point of incision constant load stretching), ≥h
/
300
Carbon black content, %
2.0-3.0
Oxidation induction time (OIT), min
Standard OIT≥100
High pressure OIT≥400
Oven aging at 85℃
Standard OIT retained after 90 days, ≥%
55
UV resistance OIT retained after 1600hrs,
≥%
50
