2014 New Type Spiral Juice Extractor

2014 New Type Spiral Juice Extractor thumbnail-1
2014 New Type Spiral Juice Extractor photo-1
US$ 2,800 - 4,500 MOQ: 1 Set
Key Specifications
Get Latest Price
Place of Origin:
Henan, China
Brand Name:
AMISY
Model Number:
ZJ-1
Contact Supplier Request Quote Chat Now
Zhengzhou Amisy Trading Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
qingdao
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Henan, China
Brand Name AMISY
Model Number ZJ-1
Processing Types Juice

Specifications

spiral fruit Juice Extractor
1.high output,operation simple
2.0.5-3 t/h fruit extractor
3.stainless steel juice extractor

 Screw Fruit Juice Extractor

introduction:

1>use-----This machine is suitable to apple, pineapple and other fruits which should be crushed when extract. The parts which will be contacted to the fruits are made by  stainless steel.

 2>Structure----Including Front-Bracket-seating ,feeding case,scew,filtering Mesh,Juice container, Back Bracket-seating, dreg out tank etc,The left side of  scew main axes is locating Roll bearing inner seat,The right side is locating in the middle seat of Roll bearing ,The motor is driving screw through a couple of triangle Belt wheel.

3>Principle--- after crushing the fruit,put the fruit pulp,juce ,skin into spiral spin juicer by hopper ,
when the material is forwarded by the helix,the spiral cylinder volume will reduce, forming to squeeze fruit material .

 4>Technical Parameter

Model

Productivity

Motor

Dimension

ZJ-0.5

0.1-0.5ton/h

1.1kw

800*320*750mm

ZJ-1.5

0.3-1.5tons/h

4kw

1560*450*1340mm

ZJ-2.5

1.0-2.5tons/h

11kw

2200*600*1560mm



5>machine related picture



2014 new type spiral Juice Extractor2014 new type spiral Juice Extractor

2014 new type spiral Juice Extractor
