2014 screw tomato juice making machine

 Screw Fruit Juice Extractor

introduction:

 1>use-----This machine is suitable to apple, pineapple and other fruits which should be crushed when extract. The parts which will be contacted to the fruits are made by  stainless steel.

 2>Structure----Including Front-Bracket-seating ,feeding case,scew,filtering Mesh,Juice container, Back Bracket-seating, dreg out tank etc,The left side of  scew main axes is locating Roll bearing inner seat,The right side is locating in the middle seat of Roll bearing ,The motor is driving screw through a couple of triangle Belt wheel.

 3>Principle--- after crushing the fruit,put the fruit pulp,juce ,skin into spiral spin juicer by hopper ,
when the material is forwarded by the helix,the spiral cylinder volume will reduce, forming to squeeze fruit material .

 4>Technical Parameter

5>machine related picture

 If you are interested in this machine, please contact
