hdpe geomembrane liner used in mud pit
thickness:0.2-4mm
width:4-8m
length:30-150m
tensile:14-27mpa
Composite geomembrane,a waterproof material,compound with geotechnological fabric and geomembrane , it is used for draining off water and adding the muscle mainly. It divides into one cloth one membrane and two cloth first membrane,width 4-6m,weight range is 200-1500g/m2.
The geomembrane is against drawing, tearing resistance,and high CBR plunger strength, can meet the need of civil engineering such as water conservancy , municipal administration,building,traffic,subway,tunnel etc.Because of selecting high polymer materials for use and adding the aging-resistant materials in the production technology, it can use in the unconventional temperature environment.
Technical Data
Item and Art No. |
PLD0601 |
PLD0602 |
PLD0603 |
PLD0604 |
PLD0605 |
PLD0606 |
PLD0607 |
Unit weight, g/m2 |
400 |
500 |
600 |
700 |
800 |
900 |
1000 |
|
Break strength, kN/m |
5 |
7.5 |
10.0 |
12.0 |
14.0 |
16.0 |
18.0 |
MD/CD CBR Plunger Strength,kN |
1.1 |
1.5 |
1.9 |
2.2 |
2.5 |
2.8 |
3.0 |
Tear strength, kN |
0.15 |
0.25 |
0.32 |
0.40 |
0.48 |
0.56 |
0.62 |
Film thickness,mm |
0.25-0.35 |
0.3-0.5 |
|||||
Technical Data
Art No. |
PLC0701 |
PLC0702 |
|
Item and Type |
GL LDPE |
GH H(Mid)DPE |
|
Material |
GL-1 GL-2 |
LDPE |
|
Thickness Range (mm) |
0.20mm-2.0mm |
0.20mm-2.0mm |
|
Carbon Content(%) |
≥2% |
≥2% |
|
Environment Stress Crack Resistance |
G/B STANDARD |
G/B STANDARD |
≥1500 |
Oxidation Inducing Time at 200 °C |
G/B STANDARD |
G/B STANDARD |
≥20 |
Tensile Strength (Mpa) |
≥14 |
≥17 |
≥25 |
Elongation (%) |
≥400 |
≥450 |
≥550 |
Right Angle Tear Strength (Mpa) |
≥50 |
≥80 |
≥110 |
Vapor Permeation (g.cm/cm2.s.pa) |
≤1.0x10-16 |
≤1.0x10-16 |
|
Soft Point(°C) |
>90 |
|
|
Crack Temperature(°C) |
<-70 |
<-70 |
|
Filter Coefficient (cm/s) |
≤10-12 |
≤10-12 |
|
