Help CenterXT4503 Carton/stretch Film Pallet Wrapping Machine
Related Products
-
YSDC-B2/B4 Pedal Cutting SealerNegotiableMOQ: 100 Units -
XT4503 Stretch Pallet Wrapper Pallet Wrapping MachineNegotiableMOQ: 100 Units
-
Semi-auto Tabletop Strapping MachineNegotiableMOQ: 3 Units
-
Automatic Wrapping MachineNegotiableMOQ: 5 Units
-
XT4503 Automatic Stretch Film Pallet Wrapping MachineNegotiableMOQ: 100 Units
Specifications
1. Suit for wrapping big objects on pallet2. Low consumption and high efficency
3. Easy operation
Description:
Adopting programmable control(frequencu converter), reliable in performance, convenient in operation; The lapping type and time can be designed on custommer's requirements.
Equipped with a photoelectric detector, automatically testing the goods height and controlling the traval limit.
Rotary table can reset automatically, thus ensuring correctin-and out position of the tray.
Convenient in film roll replacement, LLDPE film with outside diameter≤ 280mm, width≤ 500mm and paper core 76mm can be used.
Custom-made specification is available and also providing a complete set of packing system of conveying line.
Percent of pre-stretch: 250%
It can protect the package against dust and damp, and make the package clean. It can decrease the scratch of the package, improve the surface quality, and make the package more secure.
| turntable motor: | 750 w | |
| film-rack lift motor: | 180 w | |
| power supply: | 220V/380V 50HZ | |
| dimension: | 1510*2500*2600 mm | |
| max. packing height: | 2100 mm | |
| max. packing weight: | 2000 kg | |
| diameter of turntable: | 1500 mm | |
| net weight: | 530 kg | |
