Specifications
HC-50 Type Automatic Capping Machine1,Meet the GMP
2,Output:30-50 BPM
3,Material: SS 304 and SS 316
High-speed screw cap automatic capping machine
Brief Introduction:
It is an improved product based on the advantages of different capping machines. Thanks to the application of frictional capping, the capping speed is allowed being set according with the requirement of users. And even, this frictional capping machine works three times more efficient than a claw capping machine.Because of the reasonable design, it takes advantage of its compact structure, efficient work, protection to the caps and bottles,convenience in operation or maintenance, and also its stability,reliability, durability. This product conforms to the specifications of GMP absolutely. which is widely used in pharmaceutical, foods and chemical industries.
.
HC-50 Type Automatic Capping Machine Characteristic:
1,The machine is operated with direct view .
2,Governed by frequency conversion,the production speed can be randomly adjusted,automatic counting
3,The features of this machine is simple structure, stable function and easy maintenance.
HC-50 Type Automatic Capping Machine Main Technical Parameters:
Bottle Range 15-500ml
Bottle diameter 15-100mm
Bottle height 50-200mm
Bottle top diameter 20-80mm
The size of cap Height:5-40mm,diameter:20-110mm
Productivity 20-50 bottles/min
Capping Rate ≥99%
Power Supply 220V/50Hz
Power 0.75 kw
Weight 450 kg
Dimension 2000×1000×1500mm
