Specifications
1,Measurement packing machine2,Automatic packing machine
3,Automation to replace manual packing
4High efficiency,low-power
Scope of application
Vertical particles granule packing machinery
Particle automatic food packing machine :
Suitable for automatic packaging liquid, loose non-adhesive powder, particle materials like milk powder, flour, gourmet, sugar, soup, wheat and drying agents.
Technical parameters
| Model: | DXDK-20 | DXDK-40 | DXDK-150 | DXDK-500 | DXDK-1000 | |||||||
| Power: | 1.3/220 | 1.3/220 | 1.7/220 | 1.5/220 | 1.7/220 | |||||||
| (KW/V) | ||||||||||||
| Capcity: | 50-100 | 50-90 | 35-75 | 35-70 | 25-50 | |||||||
| (B/MIN) | ||||||||||||
| Packing volume: | 0.5-20 | 5-40 | 5-150 | 20-500 | 50-1000 | |||||||
| (ML) | ||||||||||||
| Bag size: | 30-120 | 50-110 | 80-150 | 50-220 | 50-300 | |||||||
| Length(mm) | ||||||||||||
| Width (mm) | 25-80 | 30-80 | 30-110 | 30-150 | 50-200 | |||||||
| Dimension:(L*W*H) | 790*600*1780 | 790*600*1780 | 800*700*1900 | 1000*860*1900 | 1000*860*1900 | |||||||
| (mm) | ||||||||||||
| Weight:(kgs) | 330 | 350 | 400 | 400 | 500 | |||||||
Function and characteristics
(1)Reasonable design, simple structure.
(2)Controlled by single-chip computer, stepping motor, convenient and correct bag length setting.
(3)Simple, fast speed regulation.
(4)Automatic completion for bag-making, filling, counting, sealing and cutting
(5)text display screen operating, convenient adjustment, high automation.
(6)Advance sensor digital-control bag making system, stable, correct bottom film run, bag length can be directly set up at operating side.
(7)Plate alignment by cursor, correct brand design can be achieved.
(8)Metering screw stem or glass devices can be optional in this machine according to different materials.
(9)Optional: ribbon coding machine. , gas-filled device (air source supplied by users).
