Half-Automatic PCB assembly line
1.Single way PVC belt conveying
2. Galvanized roller transforming
3.Independent of speed frequency
4.good quality
1. Model type: 15000 L×400w×750H(mm)
2.Single way PVC belt conveyor, galvanized roller transfer, independent frequency control of motor speed.
3.Stable performance, safety and reliability, simple operation.
ESD metal led light assembly line
Motor : |
Adopt Taiwan brand East Cropland 750W motor, WPS 60 type 1:6 0 of the speed reducer, the Chinese famous brand SONDAO 1 HP's frequency multiplier, frequency conversion sleepless speed regulation, linear speed 2-6m/min can be adjusted. |
|
Machine body & frame : |
Frame made by 40 x 40 square tube, stand by the same 40 x 40 square pipe production and become, below the belt by four points galvanized drum retainer and transfer; Leg match galvanized adjustable foot cup; Head plate with 1.2 mm cold plate bending rolling forming, body 2 meters one pieces. |
Conveying belt: |
Using the Netherlands imported high quality green light delivery special PVC belt, thickness of 2 mm, width of 400 mm, belt total length is 24000 mm, ring seamless pyro-condensation connection. |
working station : |
Long working table,made of high quality 18mm plywood specifications for the 12000 ×400×20 mm, arranged at two sides, fastening on both sides of the fuselage layout.surface treated with green antistatic materials , four sides with green T plastic strips ; fastening on both sides of the machine . |
|
Power supply arrangement: |
1.0 galvanized sheet bending and become, 2000x50x25 galvanized wire slot, is located under the fuselage belt, on both sides installation three, two square socket (every 1 m/workstation install one, bilateral installation). |
Lamp lighting |
H type light fixtures are located in the belt on both sides, choose 40 x 20 square tube welding production, connection on the machine body every 2m a frame with cold plate bending a 2000 x 50 25 plastics sprayed slot connection power, makes workers operating space more open, lighting choose 40w single belt cover fluorescent lamp, bilateral along the line arrangement. |
|
Electric devices control |
Full range of electrical control done by a distribution box, with power left and right road control |
Operation card |
Located in the middle frame processing instruction card stand all the way, uses the H - type aluminum rails manufacture, card board with A4 transparent hard plastic. |
The upper table |
15000×400×15mm,by 30L angle steel bearing ,made of 15mm high quality plywood ,surface with anti-fire materials, space between the belt is 400mm. |
conveyor belt production line,
Electronics assembly line
