Dual Zone 20ft Foot Reefer Chiller Container With Side Door

Dual Zone 20ft Foot Reefer Chiller Container With Side Door thumbnail-1
Dual Zone 20ft Foot Reefer Chiller Container With Side Door photo-1
US$ 25,000 - 28,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Type:
Reefer Container
Length (feet):
Other, 20'
Certification:
Other, CCS BV GL ABS
Contact Supplier Request Quote Chat Now
Tianjin Longteng International Trade Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Type Reefer Container
Length (feet) Other, 20'
Certification Other, CCS BV GL ABS
Capacity 59.8
External Dimensions(l x W x H)(mm) 6058*2438*2591
Internal Dimensions(l x W x H)(mm) 5898.2352.2393mm
Place of Origin Shanghai, China
Brand Name LongTeng
Model Number RF

Dual Zone 20ft foot Reefer Chiller Container with Side Door





Product Description



  • Type: 20ft 40ft reefer chiller container
  • Constrcture: dual zone chiller reefer container.
  • Certificate: GL/BV/ABS/CCS
  • Inside Temperature: -30degree celsius to + 30 degree celsius
  • MOQ: 1 pieces for 20' ft chiller/freezer twin zone storage reefer container.
  • Floor: T-Floor or flat aluminum floor
  • Optional Accessories: PVC Curtain/Container Ramp/Shelves/Meat Hanging Hook
  • Color: white or as per your request.



20ft Dual Zone Reefer Chiller Container Show

Dual Zone 20ft foot Reefer Chiller Container with Side Door



M.G.SS Shelves

Dual Zone 20ft foot Reefer Chiller Container with Side Door



With PVC Curtain & Ramp

Dual Zone 20ft foot Reefer Chiller Container with Side Door



 Dimension of Dual Zone Reefer/Chiller Container

Specifications



Dimensions

MM

FT

External

Length

6058

19'-10 1/2"

Width

2,438

8'-0"

Height

2,591

8'-6 0/10"

Internal

Length

5.456

17'-10 13/16"

Width

2,290

7'-6 3/16"

Height

2,276

7'-5 11/16"

Door Opening

Width

2,290

7'-6 3/16"

Height

2,264

7' - 5 1/8"

Inside Cubic Capacity

CU.M

CU.FT

28.4

1005



KG

LB

Maximum Gross Weight

  30480

67,196 lb

Tare Weight  (excluding reefer unit)

 3060

6750 lb

Maximum Payload

27420

60450 lb

Heat Leakage, U-Value

Max.22kcal/h°C

Air Leakage

3.5m/h (at 25.4 mm H20)

External Cladding





Side

MGSS 1.0/1/2mm

Roof

MGSS 0.8 mm

Base

MGSS 1.2 mm

Door

MGSS 1.6mm

Internal Cladding



Side

HGSS 0.7mm

Roof

P.P White Al.0.8mm

Base

40mm high AL. T-floor



Packaging & Shipping



  • Package: non packaging requirement of 20' ft chiller/freezer twin zone storage reefer container.
  • Deliver from main ports of China. Like Tianjin, ningbo, Shanghai, Xiamen and etc.



Our Services



Special Reefer Container

1. 20ft 40ft container freezer with side door

2. Deep Frozen/Ultra Freezer Container  Temperature: -60°C

3. Dual/Tripal temperature container freezer



FAQ



Q: Can container be modified to fit my needs?

A.Yes, custom container is available.



Q: What's your MOQ?

A: 1 piece for 20ft dual zone reefer container.



Q: Can I load cargo in reefer container?

A: It's called SOC. If you have cargo in China, please contact us.



Q: How can i pay?

A: We accept T/T, L/C, D/P, western union
