CE Approved UL Listed Ac/dc Power Adapter for CCTV Camera

US$ 1.9 - 2.3 MOQ: 35 Pieces

Key Specifications

Place of Origin:

Guangdong, China

Brand Name:

ACT

Model Number:

A001

Foshan City Gezheng Power Supply Technology Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Shunde

Delivery Detail:

Delivery time depends on order quantity.

Place of Origin Guangdong, China

Brand Name ACT

Model Number A001

Output Type DC

Connection Plug In

Specifications

CE approved UL listed ac/dc power adapter for CCTV Camera;
2 to 5 years warranty;
Free samples are available before order.

A001 Adapter Series

1,INPUT:100-265VAC 50//60HZ

2,The power supply has the output short circuit protection, overload protection function

3,All the products have passed the full load test process aging

4,Shell size 75*38*28mm

5,Warranty for the product is 2-5 years

6,Safety authentication:CCC,CE,UL

MODEL			A001-12-5		A001-12-12		A001-12-24		A001-15-12		A001-15-24
OUTPUT	Voltage V	5		12		24		12		24
	Current A	1.5		1		0.5		1.25		0.65
	Power W	7.5		12		12		15		15
	Load adjust rate	5%		5%		5%		5%		5%
	Linear adjust rate	3%		3%		3%		3%		3%
	Ripple noise MVp-p	80		150		180		150		180
INPUT	VoltageVAC	100~265 VAC\| 140~370 VDC
	current IA	0.2A/110VAC\| 0.1A/230VAC
	Conversion efficiency	79%		81%		82%		83%		84%
Protection function	Overload protection	When the power supply output power greater than 115% ~ 150%, the product will enter overload protection status, if solved the problems, and the power supply will resume normal work
	Short circuit protection	When the power supply output circuit, products will be in the "way of the short circuit protection hiccups" state, if the fault is eliminated, the power supply will resume normal work
Temperature	Working temperature	-20~45°C
	Storage temperature	-40~60°C
Isolation test	Isolation voltage	Input/output terminal 3000VAC,5MA
Other	Input/output port	——
	Size mm	L73 * W28 * H46
	Weight g	100G
