FRP grating, fiberglass reinforced plastic grating
Pultruded FRP Grating is built with a much stronger process, and can carry a far superior load, and handle much greater impacts than molded grating.
FRP grating, pultruded frp grating, fiberglass grating, frp pultrusion grating, trench grating, drain grating, grating walkway, platform grating
1-25mm,38mm, 40mm, 50mm,58mm,65mm high grating are available;
2-Easy to install;
3-Can be cut at any lengths you need; open area is decided by customer;
4-Grating clamps are available.
Yalong fiberglass floor grating specification list:
| Item | high A (inches) |
top wide B (mm) |
bottom wide D (mm) |
top space wide C (mm) |
theoretical weight (KG/M2) |
| 25mm I | 1 | 30 | 30 | 13 | 13 |
| 25mm I | 1 | 30 | 30 | 30 | 10 |
| 25mm I | 1 | 15 | 15 | 10 | 17 |
| 25mm I | 1 | 15 | 15 | 23 | 11 |
| 38mm I | 1.5 | 15 | 15 | 10 | 26 |
| 38mm I | 1.5 | 15 | 15 | 15 | 22 |
| 38mm I | 1.5 | 15 | 15 | 23 | 18 |
| 40mm I | 1.6 | 40 | 20 | 27 | 19 |
| 40mm I | 1.6 | 40 | 20 | 40 | 17 |
| 40mm I | 1.6 | 40 | 20 | 60 | 14 |
| 40mm I | 1.6 | 30 | 30 | 20 | 14 |
| 40mm I | 1.6 | 30 | 30 | 30 | 12 |
| 40mm I | 1.6 | 30 | 30 | 45 | 10 |
| 58mm I | 2.2 | 15 | 15 | 10 | 32 |
| 58mm I | 2.2 | 15 | 15 | 15 | 27 |
| 58mm I | 2.2 | 15 | 15 | 23 | 22 |
| 65mm I | 2.5 | 30 | 30 | 20 | 17 |
| 65mm I | 2.5 | 30 | 30 | 30 | 15 |
| 60mm I | 2.5 | 30 | 30 | 45 | 12 |
Pultruded frp grating advantages
- Corrosion Resistant.
- High Strength-to-Weight Ratio.
- Long Service Life.
- Fire Retardant.
- Slip & Impact Resistant.
- Nonconductive.
- Easy to Install & Fabricate.
Fiberglass grating Applications:
Bridge walkways
Platforms
Trench Covers
Walkways
Pedestrian Ramps
Decks and Patios
| Our fiberglass profile including | Application of our fiberglass product |
|
Fiberglass rods FRP tube (round tube, gear shape tube, square tube, rectangular tube) FRP channel FRP angle H shape beams FRP triangle support beams FRP plate other structural profiles
Window frame Shutter blade Movable Insulative Ladderspan FRP ladders and stairs Walking platform FRP handrail system FRP fence Fiberglass grating (Pultruded) Cooling tower FRP components (Filler supports, anti-freeze board) Fiberglass structure support |
|
