Opaque Quartz Glass Tube Translucent

Opaque Quartz Glass Tube Translucent photo-1
US$ 0.1 - 10 MOQ: 500 Pieces
Key Specifications
Get Latest Price
Place of Origin:
Shandong, China
Brand Name:
YUHANG
Model Number:
YH-1-102
Payment & Shipping
Payment Methods:
Port of Shipment:
Qingdao
Delivery Detail:
Delivery time depends on order quantity.
Place of Origin Shandong, China
Brand Name YUHANG
Model Number YH-1-102

Specifications

Opaque Quartz Glass Tube Translucent
High temperature resistance, good thermal stability, free selection
OD 3--500MM

Opaque Quartz Glass Tube Translucent



Item Feature:

The FIRST manufacturer has been producing it in China. No any harmful radiation and Environmental protection. No change in radioactivity for long service life, reasonable structure, Convenience usage and less thermal inertia, High temperature resistance, good thermal stability. Currently, different Out Diameter from 2mm to 500mm is our production ability.

The OH contents: ≤50ppm, ≤10ppm, ≤5ppm, ≤1ppm

Applications area: material of infrared heating lamps for heaters, micro-wave oven, electrical baking over, and sterilization container, the other consumptive and industrial infrared application.


1.Chemical Compositions
unit: ppm

Al

Cap>

Fe

Cu

Mg

Mn

4.2

1.53

0.6

0.157

0.01

0.02

2. Physics Properties

Purity (Sio2)

99.82%

Density 20°C Kg.m3(×103)

2.06—2.148

Shock Resistance KG/CM2

0.85

Softening Point°C

1600±40°C

Annealing Point°C

1120±25°C

Strain Point °C

1025±25°C

Hardness Moh’S

5—6

Dispute Pressure Intension Mpa

4134—8130

Inductivity Kv/MM

3.5

Resistance Ω.cm

20°C



Specification:

Main Dimension

(mm)

Outer Diameter

(mm)

Wall Thickness

(mm)

Length

(mm)

5-8

±0.20

±0.10

±1.0

8-12

±0.20

±0.10

±1.0

12-15

±0.20

±0.10

±1.0

15-20

±0.25

±0.10

±1.0

20-30

±0.30

±0.15

±1.0

30-60

±0.50

±0.30

±3.0
