Dongfeng Dump Truck

Name: Dongfeng Dump Truck
Brand: DALI
SKU: 106111123

US$ 20,000 - 80,000 MOQ: 1 Set

Key Specifications

Drive Wheel:

4x2

Capacity (Load):

1 - 10t

Horsepower:

150 - 250hp

Hubei Haotian Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Set

Delivery Detail:

Delivery time depends on order quantity.

Drive Wheel 4x2

Capacity (Load) 1 - 10t

Horsepower 150 - 250hp

Condition New

Transmission Type Manual

Emission Standard Euro 3

Fuel Type Diesel

Engine Capacity 4 - 6L

Gross Vehicle Weight 7310

Place of Origin Hubei, China

Brand Name DALI

Model Number DLQ5070

Dimensions (L x W x H) (mm) 6600*2400*2692

Specifications

Dongfeng Dump truck
4*2Drive configuration,140HP
Preferential price

Dongfeng Dump truck

EQ3070GSZ3GJ1 dump truck
Model	EQ3070GSZ3GJ1 dump truck	Dimension	6450,660024002692 (mm)
Chassis type	EQ3070	Cargo body size	4000,42002254600,800 (mm)
Total mass	7310 (kg)	Appearance / departure angle	30/14 (°)
Rated payload	2990 (kg)	F/R suspension	1250/1550 (mm)
Kerb weight	4125 (kg)	Maximum speed	85 (km/h)
Engine	YC4D120-30 YC4D130-30 YC4E140-31
Displacement	4214 4214 4260 (ml)	Power	90 96 103 (kw)
Manufacturer	Guangxi Yuchai Machinery Company Limited Guangxi Yuchai Machinery Company Limited Guangxi Yuchai Machinery Co., Ltd.
Emission standard	GB3847-2005,GB17691-2005 EURO3
Number of the axles	2	Front tread	1750 (mm)
Wheel base	3650,3800 (mm)	Rear tread	1700 (mm)
Number of the tires	6	Tire type	8.25-20
Fuel type	diesel	Number of the springs	9/11+8
Axle load	2750/4560(kg)	Cab Passengers	3
Others	Overall dimension: length, the dimension of van tailgate, wheelbase, departure angle, rear suspension are one-to-one correspondence relationship; the change of mass parameters is less than 3% caused by the change of dimension, it marked only one Curb weight. Dump mode is the post-tilting.
