Sino Road Wrecker

Name: Sino Road Wrecker
Brand: CNHTC
SKU: 106109211
Availability: InStock

US$ 7,000 - 70,000 MOQ: 1 Unit

Key Specifications

Fuel Type:

Diesel

Emission Standard:

Euro 3

Condition:

New

Hubei Haotian Special Automobile Co., Ltd.

Payment & Shipping

Payment Methods:

Port of Shipment:

Any port in China

Delivery Detail:

Delivery time depends on order quantity.

Fuel Type Diesel

Emission Standard Euro 3

Condition New

Transmission Type Manual

Dimensions (L x W x H) (mm) 9500*2500*3550

Place of Origin Hubei, China

Brand Name CNHTC

Model Number ZZ1256M4646C

Specifications

CNHTC Wrecker Truck
1,WD615.92 diesel engine 266hp
2,6*4 wrecker truck
3,wrecker towing speed 40km/h

This wrecker towing truck is a sample. If it can not meet your needs, Please feel free to contact me

Mainly parameters of SINOTRUCK(CNHTC) STEYR KING 6*4 Wrecker truck:

Vehicle information	After the double bridge wrecker Steyr road is our factory using the Chinese heavy truck chassis converted Steyr ZZ1256M4646C large wrecker, powerful vehicle, highway management and automotive repair shop for the ideal road wrecker truck type.
Vehicle model	HLQ5250TQZZ Wrecker Truck			Chassis model			ZZ1256M4646C
Quality parameters (kg)	Rated loading			Overall dimension			950025003550,3600(mm)
	Mass in working order		19150,20050	Van dimensions			/(mm)
	GVW		25000	Wheel base			4600+1350(mm)
Engine parameters	Model		WD615.92	Engine Type			Euro 2
	House power / Exhaust		266hp/9726	Manufacturer			China SINOTRUCK Truck Group Co., Ltd.
Performance parameters	Max speed		90 (km/h)	Tread(mm)			Front	1939,1958
	Max climbing degree		25(%)				Rear	1800,1830
	Consumption of 100 km		24(L)	Suspension(mm)			Front	1560
	Empty in Slope		20(%)				Rear	1230
	Mini turning diameter		18(m)	Drive angle(°)			Approach	15
	Mini ground clearance		248(mm)				Departure	19
Transmission	Fuller Gearbox / ZF gearbox			Tire specification			11.00-20
Cab	Flat metal roll-up , 6*4 drive
Special features	Rated the quality(kg) :5655				Max lift height (mm) (optional) :9600
	Telescopic arm stroke (mm) :1700				Telescopic crane travel (mm) (optional):3530
	Max effective arm length (mm) :2850				Max tractor speed (km/h) :40
	Max lift quality (kg)(optional) :16000				Winch	Quantity: 2
	Support legs (optional)	Quantity :2				Rated traction quality(kg): 10000*2
		Outrigger span (mm):800				Wire Rope Length(m): 40
		Max support fertility (KN):120				Twisted rope speed(m/min): 5
