Sino Road Wrecker

Sino Road Wrecker photo-1
US$ 7,000 - 70,000 MOQ: 1 Unit
Key Specifications
Get Latest Price
Fuel Type:
Diesel
Emission Standard:
Euro 3
Condition:
New
Payment & Shipping
Payment Methods:
Port of Shipment:
Any port in China
Delivery Detail:
Delivery time depends on order quantity.
Fuel Type Diesel
Emission Standard Euro 3
Condition New
Transmission Type Manual
Dimensions (L x W x H) (mm) 9500*2500*3550
Place of Origin Hubei, China
Brand Name CNHTC
Model Number ZZ1256M4646C

Specifications

CNHTC Wrecker Truck
1,WD615.92 diesel engine 266hp
2,6*4 wrecker truck
3,wrecker towing speed 40km/h

This wrecker towing truck is a sample. If it can not meet your needs, Please feel free to contact me

Mainly parameters of SINOTRUCK(CNHTC) STEYR KING 6*4 Wrecker truck:

Vehicle information

After the double bridge wrecker Steyr road is our factory using the Chinese heavy truck chassis converted Steyr ZZ1256M4646C large wrecker, powerful vehicle, highway management and automotive repair shop for the ideal road wrecker truck type.

Vehicle model

HLQ5250TQZZ Wrecker Truck

Chassis model

ZZ1256M4646C

Quality parameters

(kg)

Rated loading



Overall dimension

9500*2500*3550,3600(mm)

Mass in working order

19150,20050

Van dimensions

/(mm)

GVW

25000

Wheel base

4600+1350(mm)

Engine

parameters

Model

WD615.92

Engine Type

Euro 2

House power / Exhaust

266hp/9726

Manufacturer

China SINOTRUCK Truck Group Co., Ltd.

Performance parameters

Max speed

90 (km/h)

Tread(mm)

Front

1939,1958

Max climbing degree

25(%)

Rear

1800,1830

Consumption of 100 km

24(L)

Suspension(mm)

Front

1560

Empty in Slope

20(%)

Rear

1230

Mini turning diameter

18(m)

Drive angle(°)

Approach

15

Mini ground clearance

248(mm)

Departure

19

Transmission

Fuller Gearbox / ZF gearbox

Tire specification

11.00-20

Cab

Flat metal roll-up , 6*4 drive

Special features

Rated the quality(kg)  :5655

Max lift height (mm) (optional) :9600

Telescopic arm stroke (mm) :1700

Telescopic crane travel (mm) (optional):3530

Max effective arm length (mm) :2850

Max tractor speed (km/h) :40

Max lift quality (kg)(optional)  :16000

Winch

Quantity: 2

Support legs

(optional)

Quantity :2

Rated traction quality(kg): 10000*2

Outrigger span (mm):800

Wire Rope Length(m): 40

Max support fertility (KN):120

Twisted rope speed(m/min): 5

CONTACT NAME :Shengdong
Phone number :0086 15072962272
