Specifications
Dongfeng Tianlong 6.3 tons small-scale triaxial truck mounted crane factory directly sales1,a professional manufacturer
2 su
Dongfeng Tianlong 6.3 tons small-scale triaxial truck mounted crane factory directly sales
Dongfeng Tianlong 6.3 tons small-scale triaxial truck mounted crane factory directly
Dongfeng Tianlong small-scale triaxial Truck mounted crane | |||
Model |
Dongfeng Tianlong small-scale triaxial Truck mounted crane |
Dimension |
11540,11990×2490×3900 (mm) |
Chassis type |
DFL1203A |
Cargo body size |
7950,8400,8300×2294×550,800 (mm) |
Total mass |
20490 (kg) |
Appearance / departure angle |
30/19,30/18 (°) |
Rated payload |
8065,8000,7765,7700,7915,7850 (kg) |
F/R suspension |
1460/2780,1460/3230 (mm) |
Kerb weight |
12295,12595,12445 (kg) |
Maximum speed |
90 (km/h) |
Engine |
ISDe210 30 ISDe245 30 |
||
Displacement |
6700 6700 (ml) |
Power |
155 180 (kw) |
Manufacturer |
Dongfeng Cummins Engine Co., Ltd. |
||
Emission standard |
GB3847-2005,GB17691-2005 EURO 2 |
||
Number of the axles |
3 |
Front tread |
1980/1980 (mm) |
Wheel base |
1950+5350 (mm) |
Rear tread |
1860 (mm) |
Number of the tires |
8 |
Tire type |
10.00-20,10.00R20,11.00-20,11.00R20 |
Fuel type |
Diesel |
Number of the springs |
8/8/9+9 |
Axle load |
4995/4910/10585(kg) |
Cab Passengers |
2,3 |
Others |
Parameters correspond to relations: Dimensions length (mm) / Farm Transporter tailgate in size L / Rated contained mass (kg) / Curb Weight (kg) / crane type / model / quality (kg) / Maximum lifting load (kg): 1 .11540/7950/8065 (2), 8000 (3) / 12295 / telescopic boom / SQ8S/3200/8000; 2 .11990/8400/7765 (2), 7700 (3) / 12595 / telescopic boom / SQ10S/3500/10000; 3, 11990/8300/7915 (2), 7850 (3) / 12445 / folding arm / SQ10Z/3400/10000 | ||
The Main products are
1. Water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3.Fire engine truck
4.Truck mounted with crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck,garbage compactor truck,sealed garbage truck
9.Fecal suction truck,sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck,insulated truck,refrigeration truck
13. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer,etc more than 300 types in total.
It is just a sample,if you have any firm request ,we can discuss the detailand get a best price
Contact information:
Contact with lisa for more information and price!
phone :0086 13997889077 (24 hours)
welcome to visit our company!
we will serve you best!
