Help CenterDongfeng 5M3 Sewage Vaccum Suction Tank Truck
Related Products
Specifications
Dongfeng 5M3 sewage vaccum suction tank truck1, a professional manufacturer
2, superior quality and good price
3, the
Dongfeng 5M3 sewage vaccum suction tank truck
The truck is formed of PTO, transmission shaft, vacuum pump, tanker, hydraulic system and pipe system.
Vacuum pump is drived by PTO, to self-suck and self-discharge by four-way valve. This truck can suck the mud, sewage, dejection and the dirty water with small stone under by vacuum pump.
The truck is with self-dump, self-discharge and self-sucking function.
It will tank about 4-7min to fill of the tank body.
To make anti-rust treatment cover the inner tank body to protect the tank body
Overall dimension(mm) |
5990×2000×2500 |
Total mass(Kg) |
6495 |
Cargo box dimension(mm) |
×× |
Rated payload(Kg) |
2565 |
Appro/Depart angle |
19/15 |
Curb Weight(Kg) |
3800 |
F/R suspension(mm) |
1032/1658 |
Max.speed(km/h) |
95 |
Vehicle ID: |
LGDCM81G××××××××× |
Chassis Model |
EQ1060TJ20D3 |
Engine model |
Engine manufacturer |
Displacement |
Power (KW) |
YC4F90-30CY4102-C3FYN27CRYN30CRSD4BW70-3R4D22EYCND27-90-30YCND27-100-30CY4100-E3F |
Guangxi Yuchai Machine Co.,LtdDongfeng Chaoyao diesel Co.,LtdChengdu Yunnei Power Co.,LtdChengdu Yunnei Power Co.,LtdJiangsu Sida power Co.,LtdAnhui Quanchai power Co.,LtdGuangxi Yuchai Machine Co.,LtdGuangxi Yuchai Machine Co.,LtdDongfeng Chaoyao diesel Co.,Ltd |
265938562672297725452156265926593707 |
667066767065667573 |
Fuel type |
diesel |
Emission standard |
GB3847-2005,GB17691-2005,Euro-2 |
Axle number |
2 |
Number of tyres |
6 |
Wheel base(mm) |
3300 |
Tyre type |
7.00-16,6.50-16,7.00R16,6.50R16 |
Axle load(kg) |
2400/4095 |
Front track(mm) |
1506 |
Number of leaf spring |
8/9+5,6/8+4 |
Rear track(mm) |
1466 |
Remark |
Transport medium:liquid waste,density800kg/m3.Effective volume of tank:3-4CBM |
||
The main products are
1. Water truck
2. Fuel tanker truck, Oil Truck, Tanker Truck
3.Fire engine truck
4.Truck mounted with crane
5.Dump truck,tipper,heavy duty truck
6.LPG Tank Truck, LPG Truck, LPG Tanker, LPG Semi-trailer, LPG Storage Tanker
6. Bulk cement truck
7. Concrete mixer truck, mixer truck, cement mixer truck
8. Garbage truck, Self-loading garbage truck,garbage compactor truck,sealed garbage truck
9.Fecal suction truck,sewage suction truck
10. High altitude working truck
11. Chemical liquid truck
12. Van truck,insulated truck,refrigeration truck
13. Semi Trailer, Low plate semi-trailer,oil semi-trailer,van semi-trailer,bulk cement transportation semi-trailer,container semi-trailer,chemical liquid semitrailer,etc more than 300 types in total.
It is just a sample,if you have any firm request ,we can discuss the detailand get a best price
Contact information:
Contact with lisa to get more information and price!
24 hours phone,0086 13997889077
welcome to visit our company!
Vacuum pump is drived by PTO, to self-suck and self-discharge by four-way valve. this truck can suck the mud, sewage, dejection and the dirty water with small stone under by vacuum pump
Contact with lisa for more information and price!
phone :0086 13997889077 (24 hours)
welcome to visit our company!
we will serve you best!
1. Delivery time: within 20 working days
2. Payment : BY T/T about 30% deposit the rest be paid when the truck leave factory
3. shipping port: any port in china
