110CC QUAD Electric Start 4 Stroke

110CC QUAD Electric Start 4 Stroke thumbnail-1
110CC QUAD Electric Start 4 Stroke thumbnail-2
110CC QUAD Electric Start 4 Stroke thumbnail-3
110CC QUAD Electric Start 4 Stroke photo-1
110CC QUAD Electric Start 4 Stroke photo-2
110CC QUAD Electric Start 4 Stroke photo-3
US$ 200 - 400 MOQ: 30 Pieces
Key Specifications
Get Latest Price
Fuel:
Gas / Diesel
Displacement:
110cc
Engine Type:
4 Stroke
Contact Supplier Request Quote Chat Now
Zhejiang Liya Vehicle Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
NINGBO
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Fuel Gas / Diesel
Displacement 110cc
Engine Type 4 Stroke
Transmission Type Automatic
Transmission System Chain Drive
Certification Other, CE
Brand Name LIYA
Place of Origin Zhejiang, China
Model Number ATV503-HW

Product Description



Engine: 1 cyclinder,4 stroke, air cooled,110/125cc
Dispacement: 107ml
Compression ratio: 9.5:1
Max. power(kw/r/mim): 4.5/8000
Max. torque(N.m/r/min):5.7/5000
Transmission: Chain drive with full auto clutch
Final Drive:  14T / 37T, 420# chain
Starting system :electric start only
Ignition: C.D.I
Lighting: Front headlight with low/high beam
              Rear tail light including stoplight
Wheel & tires: high strength steel rim, 16X8-7 tire front/rear
Petrol tank volume:3L
Engine oil volume: 1.1L
Economical fuel consumption (for reference only): <= 1.9L/100km
Max. speed:  50kmph
Max load capacity: 75kgs
Brake system: Front drum brake, rear hydraulic disc brake
Suspension: Front dual A swing arm
                   rear mono shock
Dimension ( L* W * H): 1400 * 940 * 830mm
Wheelbase: 860mm
Seat height: 620mm
Min ground clerance: 110mm
Dry weight: 88kg
Color available: red,blue,yellow,black,camouflage color



8" wheels:

110CC QUAD Electric start 4 stroke

110CC QUAD Electric start 4 stroke

110CC QUAD Electric start 4 stroke




FAQ

1. Q: Can I get some samples?

A: We are honored to offer you samples for quality check.



2. Q: Do you have the products in stock?

A: No. All bikes are to be produced according to your order including samples.



3. Q: What’s the delivery time?

A: It usually takes about 25 working days to produce an order from MOQ to 40HQ container. But the exact delivery time might be different for different orders or at different time.



4. Q: Can I mix different models in one container?

A: Yes, different models can be mixed in one container, but the quantity of each model should not be less than MOQ.



5. Q: How does your factory do regarding quality control?

A: Quality is priority. LIYA People always attach great importance to quality control from the very beginning to the end of the production. Every product will be fully assembled and carefully tested before it's packed for shipment.



6. Q:What's your warranty terms?

A: We offer different warranty time for different products. Please contact with us for detailed warranty terms.



7. Q: Will you deliver the right goods as ordered? How can I trust you?

A: Yes, we will. The core of our company culture is honesty and credit. LIYA MOTO has been alibaba’s Gold supplier since 2005. If you check with alibaba, you will see that we have never got any complaint from our customers.
