Specifications
CNIX electrical rotary convection oven YZD-100(CE Approved) Manufacturer
Parameter
| Name: | Rotary Convection Oven (Diesel oil) |
| Model: | YZD-100 |
| Specified voltage: | ~ 3N 380V/50Hz |
| Productivity: | 100kg/h (bread) |
| Temperature Range: | 20-300°C |
| Drive power: | 2.38kw/h |
| Specified power: | 2.5-3 kg/h |
| Pan Size: | 400 x 600mm |
| Pan: | 16 layer x 2 = 32 trays |
| Overall dimension: | 1900 x 1800 x 2300 mm |
| Net weight: | 1300kg |
| Certificate: | ISO9001 & CE |
Remarkable Features:
1. Large baking capacity: containing baking Frame, baking 32pans each time, simple and easy to operate, saves time and effort
2. Saving the cost: stainless steel tubes and imported electric burner, to ensure use of quality but also save energy, maximize the use of cost savings.
3. Extra-thick health insulation material, reduce energy waste, make the energy consumption to a minimum.
4. Uniformity: durability: furnace temperature control instruments and separation, thermal insulation, less failure and more durable.
5. There are air volume control and humidification devices in the hot air outlet
Product introduction:
The Model YZD-100 rotary convection ovens divided into three parts electric , gas and diesel oil type .it can bake different series of bread, cake , moon cake , poultry and many other pastries .It is widely applicant to used in food factory, supermarket, bakery, department, units ,and army. Also it’s suitable for Individual food processing house, cake house, west biscuits house.
The whole adopt assembly structure, the appearance made of stainless steel , the inside of the oven which for baking is made of importing alclad sheet. The frame can moving freedom,
and the top of the inside oven has a circumrotate pothook, and adopt blast force heated air circulation; this can enhance the efficiency of the thermal transmission , and reduce the heating time, so it may cause a more frugal energy.
Note:
Our company provide different frame sections(trolley hanged at top or rotated at bottom style), which is made of materials SIS304 or SIS430. The caster wheels of the frame is high temperature for the cast iron frame caster wheels with brakes, it is flexible, durable.
