H30-6 Control High-speed Warping Machine full sets

Technical parameters:

Line Speed: 0~1000m/min

Max. Tension of line: 500N

Brake Torque :1600NM

Up and Down of Beam: Pneumatic control

Tight and release of Beam: Pneumatic control

Diameter of Speed Roller: 120mm

Power of Main Motor: 7.5kw

Control type of Main Motor: Converter Control

Monitoring Way :Immediate monitor by Microcomputer controlled touch screen

Pressure of Pneumatic source: 6bar

H30-6 warping machine is suitable for Φ30"×21" and Φ21"×21" beam.

Technical specification:

a.The main motor is controlled by converter. The constant and reliable digital pulse close ring controlled by the PLC guarantees the speed of winding and storing yarn is stable.
b.The bracket movement of beam is controlled by pneumatic, and its position is accuracy controlled by photoelectric sensor and the PLC automatically, which select the different position according to beam's diameter.

c.The tail bracket is controlled by pneumatic,and the shaft adepts centre fixing shaft head. These two features make the damage to inner beam caused by the shift lower down to the minimum.
