Raman Fiber Amplifier

Raman Fiber Amplifier thumbnail-1
Raman Fiber Amplifier thumbnail-2
Raman Fiber Amplifier thumbnail-3
Raman Fiber Amplifier photo-1
Raman Fiber Amplifier photo-2
Raman Fiber Amplifier photo-3
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
B&A
Model Number:
RA1210
Contact Supplier Request Quote Chat Now
Shanghai B&A Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name B&A
Model Number RA1210





Product Description

:

Raman Fiber Amplifier

Raman Fiber Amplifier

Features

1.Distributed low-noise amplification

2.Compact size: 1U Rack

3.Easy control and operate: Dual CPU process control, Loops and the upper  Interface respectively

4.High stability and reliability:MTBF>150000 hours

5.Perfect network Management interface:  thernet RS-485 and RS232

6.SNMP Network management Or provide SNMP Mib

7.Single channel ,DWDM  or C+L band is available

8.Intelligent temperature control system: power consumption and hot Radiation reduce 30% than common products

9.Pump polarization- Independent design

10.Compatible with Bellcore GR-1312-CORE



Application



1. SDH, ATM telecom long distance optical transmission



2. Analog digital TV long distance optical transmission system



3.  Long span system



4. 10G,40G system



Optical Characteristics





Parameters

Symbol

Min

Typ

Max

Unit

Operating wavelength

λc

1525

1550

1565

nm

Pump wavelength

λp

1425

------

1505

nm

Pump output power(1)

Po

------

500

1000

mW

ON/OFF Gain(1)

G

6

------

14

dB

Gain Flatness(2)

FL

------

1

-----

dB

Polarization Dependent Gain

PDG

------

-------

0.3

dB

PMD

PMD

------

-------

0.3

ps

Relative Noise Figure

NF

------

------

0

dB



Electric Characteristics

Parameter

Symbol

Min

Typ

Max

Unit

Power supply

Vps

85/170

110/220

132/264

VAC

Consumption

P

-----

-----

18

W

Environmental Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

Operating Temperature

Tw

-5

-----

60

℃

Storage Temperature

Ts

-40

-----

80

℃

Humidity

------

10

------

85

%







Packaging & Shipping

 Packing Details: Standard export package or customized package

Delivery Details: 7-15days





Size

 483X364X44(mm)
