Mini Fiber Optic Amplifier EDFA Module

Mini Fiber Optic Amplifier EDFA Module thumbnail-1
Mini Fiber Optic Amplifier EDFA Module thumbnail-2
Mini Fiber Optic Amplifier EDFA Module thumbnail-3
Mini Fiber Optic Amplifier EDFA Module thumbnail-4
Mini Fiber Optic Amplifier EDFA Module photo-1
Mini Fiber Optic Amplifier EDFA Module photo-2
Mini Fiber Optic Amplifier EDFA Module photo-3
Mini Fiber Optic Amplifier EDFA Module photo-4
Negotiable MOQ: 1 Piece (Price negotiable depending on order volume and customization)
Key Specifications
Get Latest Price
Place of Origin:
Shanghai, China
Brand Name:
B&A
Model Number:
M3120
Contact Supplier Request Quote Chat Now
Shanghai B&A Technology Co., Ltd.
Payment & Shipping
Payment Methods:
Port of Shipment:
Shanghai
Delivery Detail:
Delivery time depends on order quantity.

Related Products

  • Product Details

  • Company Profile
  • Contact Us
Place of Origin Shanghai, China
Brand Name B&A
Model Number M3120



Product Description

 Mini Fiber Optic Amplifier EDFA ModuleMini Fiber Optic Amplifier EDFA Module

Mini Fiber Optic Amplifier EDFA Module

Application

1.Pre-amplifier

2.In-line amplifier

3.Booster

4.DWDM Transmission system

Optical Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

wavelength

λc

1529

1550

1564

nm

Saturate Output power(1)

Po

----

------

20

dBm

Input power

Pi

-35

------

+6

dBm

Gain

G

------

20

------

dB

Noise Figure(2)

NF

------

4.5

-----

dB

Output power stability

ΔPo

-----

±0.05

±0.1

dB

Return loss

RL

-------

-------

-45

dB

Polarization dependent gain

PDG

------

-------

0.3

dB

Polarization mode dispersion

PMD

------

-------

0.5

ps



(1): 2 output ports is available



(2): Test at  0dBm input







Electric Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

voltage

Vps

3.0/4.5

3.2/5.0

3.5/5.5

VAC

consumption

P

-----

----

10

W



consumption is up to the output power and environment temperature



Environmental Characteristics



Parameter

Symbol

Min

Typ

Max

Unit

Operating temperature

Tw

-5

-----

60

℃

Storage temperature

Ts

-40

-----

80

℃

Humidity

------

10

------

85

%



(3):Non-condensing

 Order information



Product

Mechanical

Application

Input power

Output power1

Output

Ports

Voltage

Interface

M:module

31:dimension

90×70×15mm

2:fiber amplify

1:

-3~+10

dBm



9:other

13:13dBm

…

22:22dBm

1.:1 port

2: 2 ports

7:5VDC

8:3.3VDC

1: SC/UPC

2: SC/APC

3: FC/UPC

4: FC/APC

5: LC/UPC

6: LC/APC



Size



M3120: 90*70*15(mm)
